Allen-Bradley 1762-IQ16 MicroLogix 16-Point DC Input Module

Product Overview

The Allen-Bradley 1762-IQ16 is a 16-point discrete input module from the MicroLogix family, designed to expand the I/O capacity of MicroLogix 1100, 1200, and 1400 programmable logic controllers. This module supports both sinking and sourcing field devices, making it versatile for various industrial sensor and switch interfaces. Its compact footprint (3.54 x 1.59 x 3.43 inches) and dual mounting options (DIN rail or panel) simplify integration into tight control cabinets. For engineers seeking a reliable, cost-effective way to add digital inputs without replacing the entire controller, the 1762-IQ16 delivers proven performance.

Technical Specifications Breakdown

Key parameters for the 1762-IQ16 are listed below for quick reference:

Industry Applications

For example, in a packaging machine, the 1762-IQ16 can read 16 different sensor states to track product position and trigger downstream actions. Its 8.0 ms signal delay ensures reliable detection even in high-speed sorting applications. In material handling systems, the sink/source flexibility allows direct connection to both NPN and PNP sensors without additional converters, reducing wiring complexity and cost.

Installation & Setup Guidance

Mount the module on a DIN rail or panel using the provided slots, ensuring adequate clearance for the ribbon cable connection to the adjacent MicroLogix base controller. The ribbon cable supplies both bus communication and 24VDC input power. Wire field devices to the terminal block following the input numbering (bits 0–15 of word 0). Use the finger-safe cover included to prevent accidental contact. Configure input channel parameters (e.g., filter time) via the controller programming software after installation. Always remove all power before wiring or removing the module.

Maintenance & Reliability

Inspect the module periodically for dust accumulation or loose connections, especially in environments with vibration. The IP20 enclosure requires installation in a clean, dry, non-hazardous location. Avoid electrostatic discharge by grounding yourself before handling. No internal user-serviceable parts exist; if the module fails, replace it entirely. Verify that the operating voltage stays within 10…30V DC to prevent damage.

Compatibility & Integration

Expansion modules can be mixed with other MicroLogix family I/O modules. The module uses the 1762 bus interface for communication, which also provides power distribution. No additional communication protocols are required.

Selection Guide & Purchasing Advice

When selecting the 1762-IQ16, confirm that your controller supports the desired number of expansion modules and that the input voltage matches your field devices. For applications needing more than 16 inputs, consider stacking multiple modules. AutoDCSTech stocks this module and can advise on availability and lifecycle status. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
