Allen-Bradley 2097-V32PR4-LM Kinetix 350 Servo Drive 1.7 kW

Technical Specifications Breakdown

Key parameters for the 2097-V32PR4-LM are listed below for quick reference:

Industry Applications and ROI

By leveraging Ethernet/IP, it reduces wiring costs and simplifies commissioning. The integrated Safe Torque Off feature enhances operator safety without external safety relays, lowering total system cost. Compared to older analog servo drives, the Kinetix 350 offers faster setup, better diagnostics, and seamless controller integration, resulting in higher machine uptime and lower maintenance.

Installation and Setup Guidance

Mount the drive vertically on a flat panel with minimum 25.0 mm clearance above and below, and 3.0 mm on sides for airflow. Use the control power back-up input (20…26V DC, 500 mA nominal) to maintain network communication during main power loss. Ensure the AC input voltage matches the 80-264 VAC range and frequency 48-62 Hz. The drive includes an integrated AC line filter, so no external filter is required for most installations. Connect the motor phases correctly to the output terminals; the drive monitors DC bus voltage and protects against overvoltage (trip at 430 VDC).

Maintenance and Reliability

Periodically inspect the drive for dust accumulation on the heatsink and fan (if present). Keep ambient temperature within the rated range and ensure clearances remain unobstructed. The drive's solid-state design requires no routine calibration. Verify that the Safe Torque-Off circuit is tested during machine safety checks.

Kinetix 350 Servo Drive for Precision Motion Control

The Allen-Bradley 2097-V32PR4-LM is a single-axis servo drive from the Kinetix 350 series, designed for Ethernet/IP networks. It provides a cost-effective, solution for integrating MP-Series, TL-Series servo motors, and actuators with Logix controllers. This drive simplifies system configuration and reduces wiring through premiere integration with CompactLogix and ControlLogix platforms.

Compatibility and Integration

This drive is part of the Kinetix 350 motion control system and supports Ethernet/IP premiere integration with CompactLogix and ControlLogix controllers. It is compatible with MP-Series, TL-Series servo motors, and actuators. The drive parameters are accessible directly from the Logix controller for seamless programming and monitoring.

Selection Guide and Purchasing Advice

When selecting a servo drive, match the continuous and peak current ratings to your motor requirements. The 2097-V32PR4-LM provides 8.0 A RMS continuous and 24.0 A RMS peak, suitable for many medium-power applications. For higher power needs, consider other Kinetix 350 models. Contact AutoDCSTech for availability and lifecycle status.

Troubleshooting and Common Issues

If the drive fails to enable, check the Safe Torque-Off circuit is closed and the control power back-up input is within range. An overvoltage fault indicates excessive regeneration; verify the motor load and deceleration profile. Communication issues often stem from incorrect Ethernet/IP network settings or cable faults. Always refer to the user manual for detailed diagnostics.
