Technical Specifications Breakdown
Key parameters for the 2097-V34PR3-LM are listed below for quick reference:
| Feature | Specification |
|---|---|
| Input Voltage | 320-528 rms single-phase (480V nom) |
| Input Frequency | 48…62 Hz |
| Continuous Output Current (rms) | 2.0 A |
| Continuous Output Current (0-pk) | 2.8 A |
| Power Rating | 1.0 kWatts |
| Safe Torque-Off | Yes |
| Dimensions | 9.37 x 7.29 x 3.08 in (238 x 185.1 x 78.2 mm) |
| Weight | 3.3 lbs (1.5 kg) |
Industry Applications: Precision in Production
The 1.0 kW power rating and 2.0 A continuous output suit smaller servo motors for indexing, labeling, and pick-and-place tasks. Its Safe Torque-Off function enhances operator safety during maintenance without removing power.
Installation and Setup Guidance
Mount the drive in a clean, dry enclosure with adequate airflow. Use shielded motor cables and follow Rockwell Automation's wiring guidelines for the 2097-V34PR3-LM. The Ethernet/IP port allows direct connection to CompactLogix or ControlLogix controllers. Set the input voltage to 480VAC nominal (320-528VAC range) and configure parameters via the integrated web server or Studio 5000.
Maintenance and Reliability
Periodically inspect the drive for dust buildup on heatsinks and ensure ambient temperature stays within limits. The solid-state design requires no routine component replacement. Verify that the control power back-up input (20-26V DC) is functional if used for ride-through. Check Safe Torque-Off wiring annually.
The Evolution of Motion Control: Why the 2097-V34PR3-LM Matters
Industrial automation has moved from standalone drives to fully integrated motion systems. The Allen-Bradley 2097-V34PR3-LM represents this shift, combining precise servo control with native Ethernet/IP connectivity. As a Kinetix 300 series drive, it simplifies wiring and reduces cabinet space while delivering reliable performance for single-axis applications.
Compatibility and Integration
It supports indexing and point-to-point moves without a separate motion controller. The drive parameters become controller tags, simplifying programming and diagnostics.
Selection Guide and Purchasing Advice
When selecting this drive, confirm your motor's continuous current does not exceed 2.0 A rms. The 2097-V34PR3-LM is available from AutoDCSTech. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 2097-V34PR3-LM |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
