Bently Nevada 330101-14-10-10-02-05 3300 XL 8 mm Probe

Technical Specifications Breakdown

Key parameters for the 330101-14-10-10-02-05 are listed below for quick reference:

Industry Applications for Enhanced Machine Protection

Steam Turbine Monitoring

In power generation, this probe monitors shaft vibration in steam turbines. The 2 mm linear range and 7.87 V/mm scale factor provide precise data for trend analysis and trip protection.

Centrifugal Compressor Protection

For oil and gas applications, the 330101-14-10-10-02-05 detects early signs of surge or rub. The rugged PPS tip and stainless steel case withstand high temperatures and corrosive atmospheres.

Pump Health Assessment

In water treatment and chemical plants, the probe helps schedule maintenance by tracking vibration trends, reducing unplanned downtime.

Installation & Setup Guidance

Mount the probe using the 3/8-24 UNF thread. For standard forward mounted probes, recommended torque is 11.2 N•m (100 in•lbf) for the case and 7.5 N•m (66 in•lbf) for the first three threads. The recommended gap setting for radial vibration is -9 Vdc, approximately 1.27 mm (50 mils). Use 3-conductor shielded triad cable for field wiring, with maximum length of 305 meters (1,000 feet) between the probe and monitor.

Maintenance & Reliability

Inspect the probe cable and connector periodically for damage. Avoid exposing the probe to temperatures below -34˚C (-30˚F) to prevent premature failure of the pressure seal. The probe is designed to seal differential pressure using a Viton® O ring; if pressure testing is required, contact the custom design department.

Solving the Challenge of Reliable Vibration Monitoring

In rotating machinery, undetected shaft vibration can lead to catastrophic failure. The Bently Nevada 330101-14-10-10-02-05 3300 XL 8 mm Probe addresses this challenge with a robust design that withstands harsh industrial environments. This probe provides accurate, real-time displacement measurements, enabling early detection of bearing wear, imbalance, and misalignment.

Compatibility & Integration

This probe is part of the 3300 XL series and is compatible with Bently Nevada Proximitor sensors and monitoring systems. The miniature coaxial ClickLoc connector ensures secure, quick installation. The probe can be ordered with optional FluidLoc cable for applications where oil leakage through the cable interior must be prevented.

Selection Guide & Purchasing Advice

When selecting a replacement probe, verify the thread size, cable length, and connector type. The 330101-14-10-10-02-05 is a 1.0 meter probe with standard cable and ClickLoc connector. For longer cable runs, consider the 9 meter system options. Please verify current lifecycle status and availability with AutoDCSTech before ordering. AutoDCSTech stocks genuine Bently Nevada parts to ensure reliability and performance.
