Bently Nevada 330103-00-04-50-12-CN 3300 XL 8 mm Proximity Probe

Technical Specifications Breakdown

Key parameters for the 330103-00-04-50-12-CN are listed below for quick reference:

Cost-Effective Applications in Critical Machinery

Its 2 mm linear range and -9 Vdc recommended gap setting allow precise radial vibration and axial position measurement. The PPS tip withstands harsh environments, reducing replacement frequency. Using the 5-meter probe with a matching 5-meter Proximitor sensor ensures signal integrity, minimizing false trips and maintenance costs.

Installation Guidance for Reliable Operation

Proper installation maximizes probe life and measurement accuracy. The M10 x 1 thread engages up to 15 mm. Field wiring should use 0.2 to 1.5 mm² (16 to 24 AWG) three-conductor shielded triad cable, with a maximum length of 305 meters (1,000 feet) between the Proximitor sensor and monitor. Ensure the probe tip is clean and the gap set to approximately 1.27 mm (50 mils) for radial vibration applications.

Maintenance and Environmental Considerations

Inspect the probe and cable periodically for physical damage or contamination. The probe operates reliably from -52°C to +177°C, but exposure below -34°C (-30°F) may cause premature pressure seal failure. The Viton® O-ring seals differential pressure; units are not pressure tested before shipment. Contact AutoDCSTech for custom pressure testing needs.

Optimize Machinery Protection with the Bently Nevada 330103-00-04-50-12-CN

For industrial operators, unplanned downtime from rotating machinery failures can cost thousands per hour. The Bently Nevada 330103-00-04-50-12-CN 3300 XL 8 mm Proximity Probe offers a proven solution for precise shaft displacement and vibration measurement. By enabling early fault detection, this probe helps avoid catastrophic failures and extends equipment life, delivering a strong return on investment.

Compatibility and Integration

This 3300 XL 8 mm probe is designed for use with the 5-meter Proximitor sensor only. When installed with intrinsic safety barriers per drawing 141092 or galvanic isolators, it achieves Class I, Zone 0 ratings. For non-incendive circuits per drawing 140979, it meets Class I, Zone 2 requirements. Verify your system compatibility to avoid integration costs.

Purchasing Advice from AutoDCSTech

AutoDCSTech offers the Bently Nevada 330103-00-04-50-12-CN with expert support to ensure you select the correct probe length and connector for your application. Contact our team to confirm lifecycle status and availability before ordering. Investing in genuine Bently Nevada probes reduces long-term ownership costs through superior reliability.
