Product Overview
The GE IC695ETM001 is an Ethernet interface module designed for the PACSystems RX3i family, now supported by Emerson. This single-slot module provides two RJ45 ports for 10/100 Mbps Ethernet/IP communication, enabling cost-effective network integration. With a 200 MHz processor and non-volatile memory for daisy-chaining, it reduces the need for additional switches, lowering infrastructure costs.
Technical Specifications
- Ethernet Ports: 2x 10/100 Mbps (autosensing, half/full duplex)
- Serial Port: RS-232 via 9-pin female D-connector (1200 bps to 115200 bps)
- Processor Speed: 200 MHz
- Hot-Swappable: Yes (requires firmware rev 2.51)
- Non-Volatile Memory: Yes – Allows daisy-chaining of Ethernet nodes
- Connectors: 8-pin female shielded RJ45, 9-pin female D-connector
Industry Applications
- Manufacturing Cells: Use the IC695ETM001 to connect RX3i controllers to plant-wide Ethernet/IP networks. The dual ports allow daisy-chaining, saving on switch costs and cabling.
- Process Control: With Modbus TCP and SRTP protocols, this module integrates legacy Series 90 and VersaMax controllers, extending system life without full replacement.
- Remote Monitoring: The RS-232 Station Manager port provides supervisory access for diagnostics, reducing downtime by enabling remote troubleshooting.
Installation & Setup Guidance
Install the IC695ETM001 into any empty RX3i slot on compatible backplanes (IC695CHS007, CHS012, or CHS016). For hot-swap capability, ensure firmware revision 2.51 is installed. Use auto-negotiation for speed and duplex to simplify configuration. Connect the RJ45 ports to your Ethernet network; the embedded switch handles crossover detection automatically.
Maintenance & Reliability
Inspect the module quarterly for dust accumulation on the RJ45 and serial connectors. The hot-swap feature allows replacement without powering down the rack, minimizing production interruptions. Ensure the backplane is clean and free of debris to maintain reliable connections.
Compatibility & Integration
This module is compatible with all PACSystems RX3i modules except the CPE400. It supports SRTP, Modbus TCP, and Ethernet Global Data (EGD) protocols over a four-layer TCP/IP stack. Use the Station Manager for password-protected configuration and diagnostics. The SNTP time synchronization feature aligns timestamps across EGD exchanges, improving data accuracy.
Selection Guide & Purchasing Advice
When selecting the IC695ETM001, verify your system's backplane compatibility and firmware requirements. SpareTechPLC stocks this module with fast shipping. Contact our team to confirm lifecycle status and availability before ordering.
Troubleshooting & Common Issues
- No Ethernet Link: Check cable connections and auto-negotiation settings. Verify the port LEDs indicate link status.
- Serial Communication Failure: Confirm baud rate matches the connected device (1200-115200 bps). Use the Station Manager for loopback tests.
- Hot-Swap Not Working: Ensure firmware revision 2.51 is installed. Power cycle the rack if the module is not recognized.
