Honeywell TC-FIL081 Thermocouple Analog Input Module

Key Features and Benefits

The TC-FIL081 offers 8 input channels. It accepts a nominal input voltage range of ±76.5mV. This range accommodates standard thermocouple signals. The module supports ten thermocouple types: B, C, E, J, K, N, R, S, T, and TXK/XK (L). Each type covers a specific temperature range. For example, Type K spans -270 to 1372 °C (-454 to 2502 °F). Type T covers -270 to 400 °C (-454 to 752 °F). This versatility makes the module suitable for various industrial applications.

Resolution is 16 bits, with a typical value of 2.384 µV. This ensures fine temperature resolution. Accuracy with filter at 24 °C is ±0.5 °C, or 0.025% of full scale range maximum. Without filter, accuracy is 0.05% of full scale range maximum. These specifications ensure reliable measurements.

The module provides noise rejection. Normal mode rejection is -60 dB @ 60 Hz. Common mode rejection is -115 dB @ 60 Hz and -100 dB @ 50 Hz. This minimizes interference from power lines and other sources. The common mode input range is +10 V maximum. Channel-to-channel isolation is 10 V. Overvoltage capability is 35 V dc, 25 V ac continuous @ 25 °C, with 250 V peak transient. This protects the module from voltage spikes.

System throughput is 325 ms for one channel scanned, programmable to 28 ms. For eight channels scanned, throughput is 2.6 s, programmable to 224 ms. Settling time to 100% of final value is available at system throughput rate. Open circuit detection gives an out-of-range reading (upscale). Open thermocouple detection time is available at system throughput rate. Channel bandwidth is 0 to 2.62 Hz (-3 dB). RFI immunity error is less than 1% of range at 10 V/M, 27 to 1000 MHz.

Input offset drift with temperature is +6 µV/°C maximum. Gain drift is 10 ppm/°C maximum. Overall drift is 50 ppm/°C of span maximum. Cold junction compensation range is 0 to 70 °C. The module has one red/green power/status indicator. Flexbus current is 20 mA. Power dissipation is 3 W maximum @ 31.2 V dc. Thermal dissipation is 10.2 BTU/hr @ 31.2 V dc. Keyswitch position is 3.

External DC power supply voltage is 24 V dc nominal. Voltage range is 19.2 to 31.2 V dc (includes 5% ac ripple). Supply current is 150 mA @ 24 V dc. Dimensions are HxWxD 1.8 mm x 3.7 mm x 2.1 mm (46 in x 94 in x 53 in). Operational temperature is 0 to 55 °C (32 to 131 °F). Storage temperature is -40 to 85 °C (-40 to 185 °F). Relative humidity is 5 to 95% non-condensing (operating) and 5 to 80% non-condensing (non-operating). Shock (operating) is 30 g peak acceleration, 11(±1) s pulse width. Shock (non-operating) is 50 g peak acceleration, 11(±1) s pulse width. Vibration tested at 5 g @ 10-500 Hz per IEC 68-2-6. Agency certifications include Groups A, B, C, D, Class I Division 2, and Class I Zone 2 Group IIC.

Technical Specifications Breakdown

Key parameters for the TC-FIL081 are listed below for quick reference:

Industry Applications

In chemical processing, it monitors reactor temperatures. The Type K and Type J ranges cover typical process temperatures. In power generation, it monitors boiler and turbine temperatures. The high accuracy and noise rejection ensure stable readings. In food and beverage, it monitors pasteurization and sterilization. The module's robust design handles harsh industrial environments.

Installation and Setup Guidance

Proper installation ensures optimal performance. Mount the module securely in the designated slot. Ensure the keyswitch position is set to 3. Connect external DC power within the specified range (19.2 to 31.2 V dc). Use shielded thermocouple wires to minimize noise. Route wires away from high-voltage lines. Configure the module using the control system software. Set the data format to 16-bit 2's complement or offset binary. For unipolar operation, select the appropriate format. Verify the cold junction compensation range (0 to 70 °C) matches the environment.

Maintenance and Reliability

Regular inspection is essential for long-term reliability. Check the module's status indicator periodically. Ensure the power supply remains within the specified voltage range. Keep the ambient temperature within the operational range (0 to 55 °C). Avoid exposing the module to excessive vibration or shock. The module is tested to withstand 30 g operating shock and 50 g non-operating shock. Clean the module and surrounding area to prevent dust accumulation. Follow the manufacturer's guidelines for any maintenance procedures.

The Evolution of Precision Temperature Measurement

Industrial processes have evolved from manual monitoring to sophisticated distributed control systems. Temperature measurement remains the backbone of quality and safety. The Honeywell TC-FIL081 thermocouple analog input module represents this evolution. It delivers reliable, high-resolution data acquisition for demanding applications. This module converts small thermocouple voltages into precise digital readings. It helps engineers maintain tight process control and reduce downtime.

Compatibility and Integration

The TC-FIL081 is designed for Honeywell control systems. It communicates via the Flexbus interface. The module is compatible with systems that support Flexbus. It provides 20 mA of Flexbus current. Integration is straightforward with Honeywell's configuration tools. The module's data format is compatible with standard control logic.

Selection Guide and Purchasing Advice

When selecting a thermocouple input module, consider the number of channels and supported thermocouple types. The TC-FIL081 offers 8 channels and supports 10 types, making it versatile. Ensure the module meets your system's voltage and environmental requirements. For purchasing, contact AutoDCSTech. They provide genuine Honeywell parts and expert support. Verify the lifecycle status and availability before ordering. AutoDCSTech can assist with any questions.

Troubleshooting and Common Issues

If the module reads out of range, check for open thermocouple connections. The module indicates open circuit with an upscale reading. Verify the thermocouple type is correctly configured. If readings are noisy, check the shielding and grounding. Ensure the module is within the specified temperature range. If the status indicator is red, check the power supply. Confirm the voltage is within 19.2 to 31.2 V dc. If issues persist, consult the system documentation or contact AutoDCSTech for support.
