Lenze K-D M12W-3P-2m-PVC Connection Cable – 2m PVC M12 Angular 3-Pin

Technical Specifications Breakdown

Key parameters for the K-D M12W-3P-2m-PVC are listed below for quick reference:

Industry Applications

Automotive Assembly Lines – The 2m length and angular connector fit neatly in robotic cells where space is limited. The PVC jacket resists oils and coolants commonly found in machining areas.

Packaging Machinery – With a rated voltage of ≤250VAC/DC and current capacity of ≤4A per contact, this cable reliably powers sensors and actuators in high-speed packaging equipment. The fixed wiring temperature range of -30°C to +70°C suits unconditioned factory floors.

Material Handling Systems – The angular M12 connector simplifies routing along conveyor frames, reducing the risk of cable damage. The self-locking screw fitting (recommended torque 0.6Nm) ensures a secure connection even under vibration.

Installation & Setup Guidance

• Torque: Tighten the coupling nut to 0.6Nm as recommended. Over-tightening can damage the threads.
• Bending Radius: For flexible wiring, avoid bending the cable tighter than 10 times the sheath diameter. This prevents internal conductor stress.
• Cable Routing: Use the angular connector to direct the cable parallel to the mounting surface, minimizing protrusion and snagging.
• Temperature Consideration: If the cable will flex during operation, ensure the ambient temperature stays within -5°C to +70°C. For fixed installations, -30°C to +70°C is acceptable.

Maintenance & Reliability

Periodic inspection is recommended to maintain signal integrity. Check the connector for signs of corrosion or looseness. Verify that the cable jacket is free from cuts or abrasion, especially near the connector strain relief. Clean the connector contacts with a dry, lint-free cloth if contamination is visible. Avoid using solvents that could degrade the PVC or TPU materials.

Why Do Connection Cables Fail in Harsh Industrial Environments?

In automated production lines, sensor and actuator cables often become the weakest link. Vibration, flexing, and temperature extremes can cause intermittent signals or complete downtime. The Lenze K-D M12W-3P-2m-PVC connection cable is engineered to address these challenges with a robust design and reliable electrical performance.

What Is the Lenze K-D M12W-3P-2m-PVC?

This is a factory-made connection cable featuring a right-angle M12 connector with three pins. The cable length is 2 meters, and the jacket is made of PVC. It is part of the Leuze K-D series, known for durable connectivity solutions in industrial automation. The angular design helps route cables in tight spaces, reducing strain on the connector.

Compatibility & Integration

The K-D M12W-3P-2m-PVC is a standard M12 3-pin connection cable, compatible with most industrial sensors and actuators that use M12 connectors. It is not brand-specific, making it a versatile replacement for many OEM cables. The PVC jacket provides good resistance to industrial oils and chemicals, while the TPU handle body offers durability.

Selection Guide & Purchasing Advice

When selecting a connection cable, consider the required length, pin count, and environmental conditions. If you need a different length or pin configuration, AutoDCSTech can assist with other options in the K-D series.

Before ordering, verify the current lifecycle status and availability with AutoDCSTech. They stock a wide range of industrial automation parts and can provide fast, reliable delivery.

Troubleshooting & Common Issues

Intermittent Signal – Check the connector for loose coupling. Ensure the torque is 0.6Nm. Inspect the cable for kinks or sharp bends that could break internal wires.

No Communication – Verify that the pinout matches your device. The 3-pin configuration is standard for many sensors, but always confirm with your device manual.

Cable Damage – If the jacket shows cuts or abrasion, replace the cable immediately to avoid short circuits. Use cable ties or clamps to secure the cable and prevent movement.

Temperature Issues – If the cable is exposed to temperatures outside the rated range, the PVC jacket may become brittle or soft. Ensure the operating environment stays within the specified limits.

For further assistance, contact AutoDCSTech with your application details. Their technical team can help you select the right cable for your specific requirements.
