Lenze K-D M12W-4P-2m-PVC M12 Angled Cable, 4-Pin, 2m PVC

Technical Specifications Breakdown

Key parameters for the K-D M12W-4P-2m-PVC are listed below for quick reference:

Industry Applications

Space-Constrained Automation Cells

Robotic workstations often have limited clearance around sensors and actuators. The angled M12 connector on this cable reduces bend radius requirements, allowing neat routing in tight panels or along machine frames. This minimizes stress on the cable and prevents intermittent signals.

High-Vibration Environments

The screw fitting with diecast zinc nickel-plated locking mechanism provides a secure connection that resists loosening from vibration. Recommended torque of 0.6 Nm ensures consistent clamping without damaging the threads, making it suitable for conveyors, packaging machinery, and material handling equipment.

Flexible Wiring Applications

For moving cable tracks or robotic arms, the flexible wiring temperature range of -5 °C to +70 °C ensures reliable operation even under dynamic flexing. The PVC jacket offers good abrasion resistance while maintaining flexibility, reducing the risk of conductor fatigue.

Installation & Setup Guidance

When installing the K-D M12W-4P-2m-PVC, ensure the connector is aligned correctly before tightening. Hand-tighten the coupling nut, then use a wrench to apply the recommended torque of 0.6 Nm. Avoid over-tightening, which can damage the O-ring or threads. For fixed installations, secure the cable with strain relief to prevent pulling forces from transmitting to the connector. Observe the minimum bending radius of 10 times the sheath diameter to maintain cable integrity.

Maintenance & Reliability

Periodically inspect the connector for signs of wear, corrosion, or loose fittings. In harsh environments with chemicals or moisture, verify that the PVC jacket remains intact and the locking nut is snug. Clean the connector surfaces with a dry cloth if contamination is visible. Avoid using solvents that may degrade the PVC or TPU materials. Regular checks help extend service life and prevent unexpected failures.

Reliable Signal Transmission for Demanding Industrial Environments

In automated production lines, a single faulty connection can halt an entire process, leading to costly downtime and diagnostic headaches. Engineers often face the challenge of maintaining signal integrity in tight spaces where straight connectors are impractical. The Lenze K-D M12W-4P-2m-PVC connection cable addresses this by providing a robust, angled M12 interface with a flexible PVC jacket, ensuring reliable performance in space-constrained installations.

Compatibility & Integration

The K-D M12W-4P-2m-PVC is a standard M12 4-pin cable, compatible with a wide range of industrial sensors, actuators, and I/O blocks that use M12 connectors. Its angled design is particularly useful when connecting to devices mounted flush against surfaces. The 2-meter length offers flexibility in routing while keeping signal paths short. Always verify that the device's electrical ratings do not exceed the cable's maximum voltage and current limits.

Selection Guide & Purchasing Advice

When selecting a connection cable, consider the environmental conditions, cable length, and connector orientation. The K-D M12W-4P-2m-PVC from Lenze is a dependable choice for most industrial applications. Our team can confirm stock, provide cross-reference support, and advise on alternatives if needed. Ensure you order the correct part number to match your system requirements.

Please verify current lifecycle status and availability with AutoDCSTech before ordering.
