Product Overview
When factory automation demands reliable control without overspending, the Mitsubishi FX2N-64MR-001 delivers. This Fx2n Series Programmable Controller balances performance and cost, making it a practical choice for medium-scale applications. With 64 total input/output points, it handles diverse tasks while keeping your budget in check.
Technical Specifications Breakdown
The FX2N-64MR-001 operates on a supply voltage of 100-240VAC, consuming only 60VA. This wide voltage range reduces power supply costs and simplifies installation across different regions. The relay output type provides robust switching for inductive loads, lowering replacement expenses over time. With 32 input points and 32 output points, you get balanced I/O allocation without paying for unused channels. The unit weighs 1.0 kg and measures 220x90x87 mm, fitting neatly into standard enclosures to save panel space.
Industry Applications
In packaging lines, the FX2N-64MR-001 controls conveyor sequences and actuator timing. Its relay outputs handle motor starters and solenoids directly, reducing the need for external interface relays. For material handling systems, the 64 I/O points manage sensors and actuators efficiently, minimizing controller costs per machine. The built-in 8K RAM memory (expandable to 16K) supports complex logic without requiring expensive memory upgrades.
Installation & Setup Guidance
Mount the FX2N-64MR-001 on a DIN rail or panel using the provided slots. Connect the 100-240VAC supply to the dedicated terminals, ensuring proper fusing. Wire input devices to the 24VDC input terminals, observing polarity. For relay outputs, use appropriate contact protection for inductive loads. The quick-disconnect terminal blocks simplify wiring changes, reducing downtime during commissioning.
Maintenance & Reliability
Inspect relay contacts periodically for wear, especially in high-cycle applications. The 60VA power consumption keeps heat generation low, extending component life. Keep the enclosure clean and ensure adequate ventilation around the 220x90x87 mm unit. Regular backups of the 8K RAM memory prevent program loss. These simple steps maximize uptime and avoid costly repairs.
Compatibility & Integration
The FX2N-64MR-001 accepts input/output expansion modules and special function modules on its right side. This modularity lets you scale I/O or add analog capabilities without replacing the main unit. The 2-axis positioning function (transistor output type) integrates motion control directly, saving the cost of a separate motion controller.
Selection Guide & Purchasing Advice
Before ordering, confirm your total I/O requirement does not exceed 64 points. Verify the relay output rating matches your load specifications. The FX2N-64MR-001 is available at SpareTechPLC, your reliable source for industrial automation parts. Contact our team to check current lifecycle status and availability.
Frequently Asked Questions
What is the supply voltage range for the FX2N-64MR-001?
The supply voltage is 100-240VAC, as specified in the product data.
How many input and output points does this controller have?
It has 32 input points and 32 output points, totaling 64 I/O points.
What type of output does the FX2N-64MR-001 use?
It uses relay output, suitable for switching AC or DC loads up to the relay rating.
Can I expand the I/O capacity of this unit?
Yes, you can connect input/output expansion modules and special function modules on the right side.
What is the power consumption of this PLC?
The power consumption is 60VA.
