Introduction
In the evolving landscape of industrial automation, the need for precise and reliable control has never been greater. As factories transition from manual processes to networked systems, the Mitsubishi FX3GA-40MR-CM emerges as a cornerstone for modern automation. This MELSEC-F Standard Model is designed to bridge the gap between basic control functions and advanced network communications, ensuring seamless operations in demanding environments.
Product Overview
The Mitsubishi FX3GA-40MR-CM is a MELSEC-F Standard Model from Mitsubishi Electric, engineered for precision control across automation and network communications. It provides basic control functions essential for a wide range of industrial applications. With a rated voltage of AC100 to 240V and a permissible voltage range of AC85 to 264V, this unit adapts to varying power conditions. Its rated frequency of 50/60Hz makes it suitable for global use.
Technical Specifications Breakdown
Key specifications of the FX3GA-40MR-CM include:
- Power Consumption: 37W, ensuring energy-efficient operation.
- Supply Power Capacity: 400mA, supporting connected peripherals.
- Inrush Current: Maximum 30A at 5ms or less for AC100V, and maximum 50A at 5ms or less for AC200V, providing robust startup performance.
- Power Fuses: 250V 3.15A, protecting against overcurrent.
- Allow Momentary Power Failure Time: Instant power failure below 10ms allows continued operation, enhancing reliability.
- Weight: 0.70 Kg, making it lightweight and easy to install.
These parameters ensure the FX3GA-40MR-CM delivers consistent performance in automated systems.
Industry Applications
The FX3GA-40MR-CM is ideal for manufacturing lines, packaging machinery, and material handling systems. For example, in a bottling plant, it controls conveyor speed and filling operations with precision. Its ability to handle momentary power failures below 10ms prevents costly downtime. This reliability translates to long-term cost savings, as fewer interruptions mean higher productivity and reduced maintenance expenses.
Installation & Setup Guidance
When installing the FX3GA-40MR-CM, ensure the power supply matches the rated voltage of AC100 to 240V. Mount the unit in a clean, dry enclosure away from excessive vibration. Connect the power fuses (250V 3.15A) as specified to protect the system. Verify that the supply power capacity of 400mA is sufficient for all connected devices. Follow standard wiring practices for MELSEC-F series controllers.
Maintenance & Reliability
Regular maintenance of the FX3GA-40MR-CM includes inspecting power connections and fuses. Check for signs of dust or moisture, which can affect performance. The unit's ability to continue operation during momentary power failures below 10ms reduces wear on components. By maintaining a clean environment and verifying power quality, you extend the lifespan of this PLC, maximizing your return on investment.
Compatibility & Integration
The FX3GA-40MR-CM integrates seamlessly with other MELSEC-F series components and Mitsubishi automation systems. It supports network communications for data exchange and remote monitoring. While specific protocols are not listed in the provided data, its design ensures compatibility with standard industrial networks used in MELSEC-F environments.
Selection Guide & Purchasing Advice
Before purchasing the FX3GA-40MR-CM, verify your system's voltage requirements (AC100-240V) and power consumption (37W). Ensure the enclosure accommodates its dimensions (W: 130mm, W1: 122mm) and weight (0.70 Kg). SpareTechPLC offers this model with detailed support to help you select the right automation solution. Contact us for current lifecycle status and availability.
Frequently Asked Questions
Q1: What is the rated voltage for the FX3GA-40MR-CM?
A1: The rated voltage is AC100 to 240V, with a permissible range of AC85 to 264V.
Q2: How much power does the FX3GA-40MR-CM consume?
A2: It consumes 37W of power.
Q3: Can the FX3GA-40MR-CM handle momentary power failures?
A3: Yes, it continues operation during power failures below 10ms.
Q4: What is the weight of the FX3GA-40MR-CM?
A4: The weight is 0.70 Kg.
Q5: What type of fuses does the FX3GA-40MR-CM use?
A5: It uses 250V 3.15A power fuses.
