Introduction: Solve Control Challenges with the FX3GA-60MR-CM
When industrial automation demands precise control and seamless network integration, the Mitsubishi FX3GA-60MR-CM MELSEC-F Standard Model delivers reliable performance. This compact PLC handles basic control functions while supporting communication tasks, making it a versatile choice for manufacturing lines, packaging systems, and material handling equipment.
Technical Specifications Breakdown
The FX3GA-60MR-CM operates on a rated voltage of AC100 to 240V with a permissible voltage range of AC85 to 264V. It accepts a rated frequency of 50/60Hz, ensuring compatibility with global power grids. The power failure time allows instant interruptions below 10ms without stopping operation. Inrush current is limited to 30A max for 5ms or less at AC100V and 50A max at AC200V. Power consumption is 40W, and the supply power capacity is 400mA. The unit measures 175 mm in width (W) and 167 mm in width (W1), with a weight of 0.85 kg. A 250V 3.15A fuse protects the system.
Industry Applications
In packaging lines, the FX3GA-60MR-CM controls conveyor timing and sealing mechanisms with its reliable power supply and fast response to power interruptions. For material handling systems, it coordinates sorting and stacking operations, leveraging its 40W power consumption to minimize energy costs. The PLC's ability to handle instant power failures below 10ms ensures continuous operation in critical processes, reducing downtime and maintenance expenses.
Installation & Setup Guidance
Mount the FX3GA-60MR-CM on a DIN rail or panel using the provided slots. Ensure the AC power source matches the permissible voltage range of AC85 to 264V. Connect the 250V 3.15A fuse in series with the line input. Verify that the total current draw from the 400mA supply power capacity does not exceed the limit. Use shielded cables for communication lines to reduce electromagnetic interference.
Maintenance & Reliability
Inspect the power fuse and input connections periodically to ensure secure contacts. Check for dust accumulation on the ventilation slots and clean with a dry cloth if needed. The unit's instant power failure tolerance below 10ms reduces wear on internal components, extending service life. Regular verification of the rated voltage and frequency prevents operational issues.
Selection Guide & Purchasing Advice
Before ordering, confirm that your application requires a MELSEC-F Standard Model with the FX3GA-60MR-CM's specifications. Verify the AC power source matches AC100-240V and the frequency is 50/60Hz. Ensure the physical dimensions (175 mm width) fit your enclosure. SpareTechPLC stocks this model and can provide availability details. Please verify current lifecycle status and availability with SpareTechPLC before ordering.
Frequently Asked Questions
What is the rated voltage for the FX3GA-60MR-CM?
The rated voltage is AC100 to 240V, with a permissible range of AC85 to 264V.
How much power does the FX3GA-60MR-CM consume?
Power consumption is 40W, with a supply power capacity of 400mA.
What happens during a power failure?
Instant power failures below 10ms allow the PLC to continue operation without interruption.
What are the dimensions and weight of the FX3GA-60MR-CM?
Width is 175 mm (W) and 167 mm (W1), with a weight of 0.85 kg.
What fuse rating does the FX3GA-60MR-CM require?
A 250V 3.15A fuse is specified for protection.
