Why Choose the 110XTS00122 for Your Control System?
Struggling to integrate I/O modules with legacy or modern networks? The Schneider Electric 110XTS00122 I/O base module bridges the gap with flexible mounting and dual-protocol communication.
Product Overview
The 110XTS00122 is an I/O base module from Schneider Electric's Modicon Momentum series. It provides a single base slot for mounting a Momentum processor or I/O modules. Designed for versatile installation, it supports both DIN rail and panel mounting. The module communicates via Modbus Plus or Ethernet, making it suitable for diverse industrial networks.
Technical Specifications Breakdown
Key parameters for the 110XTS00122 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon Momentum |
| Part Number | 110XTS00122 |
| Name | I/O Base Module |
| Mounting Type | DIN Rail or Panel Mount |
| Bus Type | Modbus Plus / Ethernet Communication |
| Number of Slots | 1 Base Slot |
| Supported Devices | Momentum Processor and I/O Modules |
| Operating Voltage | 5 VDC (from Processor Module) |
| Power Consumption | Low power consumption design |
| Protection Class | IP20 |
| Material | High-impact plastic |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Humidity | 5% to 95% non-condensing |
Industry Applications
This I/O base module is ideal for discrete manufacturing and process control systems that require reliable communication between controllers and field devices. Its Modbus Plus and Ethernet support allows seamless integration into both legacy and modern architectures. The low power consumption makes it suitable for energy-sensitive installations.
Installation & Setup Guidance
Mount the module on a standard DIN rail or directly on a panel using the integrated slots. Ensure the processor module supplies 5 VDC to the base. Connect the communication bus using Modbus Plus or Ethernet cabling as per your network topology. Secure all connections to maintain IP20 protection.
Maintenance & Reliability
The high-impact plastic enclosure provides durability in industrial environments. Operate within 0 °C to 60 °C and store between -40 °C to 85 °C. Keep humidity between 5% and 95% non-condensing. Periodically inspect the module for dust accumulation and verify that all connections remain tight.
Compatibility & Integration
The 110XTS00122 is compatible with Modicon Momentum processors and I/O modules. It supports Modbus Plus and Ethernet communication protocols, enabling integration with Schneider Electric and third-party systems.
Selection Guide & Purchasing Advice
When selecting this module, confirm your system requires a single-slot I/O base with Modbus Plus or Ethernet. For availability and lifecycle status, contact SpareTechPLC. We stock genuine Schneider Electric parts ready to ship.
Troubleshooting & Common Issues
If communication fails, verify the bus cable integrity and termination. Ensure the processor module is powered and providing 5 VDC to the base. Check that the I/O module is properly seated in the slot. For persistent issues, consult the Modicon Momentum user manual.
