Schneider 170XCP20000 Cable Coding Kit for Modicon Momentum

Product Overview

The 170XCP20000 is a cable coding kit manufactured by Schneider Electric as part of the Modicon Momentum product line. It is designed to facilitate clear cable identification and organization within industrial control panels. With its compact dimensions—1.18 inches in height, 4.33 inches in width, and 9.84 inches in length—it fits easily into tight spaces. The kit weighs only 53 grams, making it lightweight and easy to handle during installation.

Technical Specifications Breakdown

Key parameters for the 170XCP20000 are listed below for quick reference:

Industry Applications

By providing clear physical identification of cables, it reduces the risk of misconnection during installation or maintenance. The wide operating temperature range (0 to 60 degrees Celsius) and high humidity tolerance (95% non-condensing) make it suitable for both climate-controlled facilities and harsher industrial settings. The altitude rating of 1000m ensures reliable performance in most lowland and mid-altitude plants.

Installation & Setup Guidance

When installing the 170XCP20000, ensure the ambient temperature stays within 0 to 60 degrees Celsius and that humidity remains below 95% non-condensing. The kit is designed for natural cooling, so avoid enclosing it in sealed compartments without airflow. Mount it securely in the designated slot within the Modicon Momentum backplane. Use the provided coding elements to label cables according to your wiring diagram. Always verify that the kit is fully seated before powering the system.

Maintenance & Reliability

Periodically inspect the cable coding kit for signs of wear or loosening. Because the kit relies on natural cooling, keep surrounding ventilation paths clear of dust and debris. The non-condensing humidity limit of 95% should be respected to prevent moisture ingress. No routine calibration or part replacement is required under normal conditions. If the coding elements become illegible, replace them promptly to maintain clarity.

Streamlining Cable Management in Modern Automation

The Schneider Electric 170XCP20000 cable coding kit addresses this challenge directly, offering a standardized solution for the Modicon Momentum series. This component helps reduce wiring errors and simplifies maintenance, supporting uptime in demanding environments.

Compatibility & Integration

The 170XCP20000 is engineered specifically for the Modicon Momentum series from Schneider Electric. No special software or configuration is needed—the kit provides physical coding only. Ensure your system uses the correct part number for compatibility.

Selection Guide & Purchasing Advice

When selecting a cable coding kit for your Modicon Momentum system, verify that the part number matches 170XCP20000. This kit is available from AutoDCSTech, a trusted supplier of industrial automation parts. Before ordering, please verify current lifecycle status and availability with AutoDCSTech. The compact size and lightweight design (53 grams) make it easy to stock spares for multiple panels.
