Product Overview
The 170XCP10000 is a cable coding kit designed specifically for I/O bases in the Modicon Momentum series by Schneider Electric. This kit physically keys cables to prevent incorrect insertion, reducing installation errors and simplifying maintenance. Its compact dimensions (1.18 inches high, 4.33 inches wide, 9.84 inches long) and light weight (53 grams) allow easy integration into dense panel layouts. The kit meets CE standards, ensuring compliance with European safety and performance regulations.
Technical Specifications Breakdown
Key parameters for the 170XCP10000 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Cable Coding Kit for I/O Bases |
| Product Line | Modicon Momentum |
| Part Number | 170XCP10000 |
| Height | 1.18 inches |
| Width | 4.33 inches |
| Length | 9.84 inches |
| Standard Compliance | CE |
| Cooling | Natural |
| Maximum Ambient Temperature | 60 degrees Celsius |
| Minimum Ambient Temperature | 0 degrees Celsius |
| Max. Operating Humidity | 95% (non-condensing) |
| Max. Storage Humidity | 95% (non-condensing) |
| Max. Altitude | 1000m above sea level |
Industry Applications
Control Panel Assembly and Maintenance
In manufacturing facilities, technicians frequently connect and disconnect I/O modules. The 170XCP10000 coding kit eliminates wiring errors by mechanically enforcing correct cable-to-base pairing. This reduces commissioning time and prevents accidental short circuits.
Process Automation Environments
For continuous processes like chemical or food production, system uptime is critical. Using this kit minimizes human error during module replacements, keeping production lines running reliably.
Remote or Harsh Installations
With an operating temperature range of 0 to 60 degrees Celsius and humidity tolerance up to 95% non-condensing, this kit suits environments like outdoor skids or unheated warehouses. Its 1000m altitude rating allows use in high-altitude facilities.
Installation & Setup Guidance
Before installation, verify that the I/O base is clean and free of debris. Align the coding key with the corresponding slot on the base and press firmly until it clicks into place. Ensure the cable connector matches the key orientation before mating. Always follow the Momentum system manual for torque specifications on terminal screws. Test continuity after installation to confirm proper seating.
Maintenance & Reliability
Inspect the coding keys periodically for wear or damage, especially in high-vibration environments. The natural cooling design requires no active airflow, but ensure ventilation paths are unobstructed. Keep humidity below 95% to avoid condensation. Replace any cracked or deformed keys immediately to maintain coding integrity.
Why Proper Cable Coding Matters in Industrial Automation
In complex control panels, miswired I/O connections can lead to costly downtime and equipment damage. How do you ensure every cable connects to the correct base without guesswork? The Schneider 170XCP10000 cable coding kit provides a simple, mechanical solution for Modicon Momentum systems.
Compatibility & Integration
This kit is designed exclusively for Modicon Momentum I/O bases. The mechanical coding is independent of communication protocols, making it compatible with all Momentum bus couplers.
Selection Guide & Purchasing Advice
When ordering the 170XCP10000, confirm your I/O base model to ensure correct key profile. AutoDCSTech stocks genuine Schneider parts with fast shipping. Please verify current lifecycle status and availability with AutoDCSTech before ordering. For bulk projects, inquire about quantity discounts to reduce per-unit costs.
Availability & Condition at AutoDCSTech
| Part Number | 170XCP10000 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
