ATV71HD15N4: Variable Speed Drive
The ATV71HD15N4 is the Variable Speed Drive covered on this page. The attribute that decides whether it fits the existing installation without modification is 15.7 x 9.06 x 8.4 in.
On this unit variable speed drive is the figure that decides fit and function. A variable-speed or soft-start device is specified by the motor it must control and the starting or speed regime it must deliver. variable speed drive sets the current or power rating, the control method and the enclosure or network option — the things that decide whether the device starts the load without tripping and integrates with the existing control. Verifying 15.7 x 9.06 x 8.4 in against the motor nameplate and the control architecture prevents a drive that fits the panel but cannot carry the load.
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Brand | Schneider |
| Part Number | ATV71HD15N4 |
| Product Type | Variable Speed Drive |
| Product Line | Altivar 71 |
| Part Number | ATV71HD15N4 |
| Motor Power | 15 kW (20 hp) |
| Voltage Rating | 380 - 408 V AC |
| Phase | 3-phase |
| Input Current | 48 A at 380 V, 39 A at 480 V |
| Output Frequency | 0.1…599 Hz |
| Nominal Switching Frequency | 4 kHz |
| EMC Filter | Integrated |
| Graphic Terminal | Included |
| Communication | Modbus, CANopen |
| Protection Degree | IP20 |
| Weight | 28.7 lb (13 kg) |
| Dimensions | 15.7 x 9.06 x 8.4 in |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| schneider-atv71hd15n4z-altivar-71-15-kw-variable-speed-drive-for-industrial | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | ATV71HD15N4 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
