BMXDAO1605: Modicon X80 Discrete Output Module 16 Triac Outputs
The BMXDAO1605 is the Modicon X80 Discrete Output Module 16 Triac Outputs covered on this page. The attribute that decides whether it fits the existing installation without modification is 0...60 Degrees Celsius.
The reason to specify this exact variant is modicon x80 discrete output module 16 triac outputs. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. modicon x80 discrete output module 16 triac outputs sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 0...60 Degrees Celsius against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Brand | Schneider |
| Part Number | BMXDAO1605 |
| Product Line | Modicon |
| Part Number | BMXDAO1605 |
| EAN | 3595863966954 |
| Weight | 0.50 lbs (0.23 kg) |
| Product | Discrete Output Module |
| Output Number | 16 |
| Output Type | Triac |
| Discrete Output Voltage | 100 to 240 Volts AC |
| Discrete Output Current per Channel | 0.6 Amps |
| Inrush Current | 20 Amps |
| Protection Type | 1 External Fuse Fast Blow |
| Maximum Current per Output Common | 2.4 Amps |
| IP Rating | IP 20 |
| Status LEDs | Included |
| Recommended Environment | Indoors |
| Operating Temperature | 0...60 Degrees Celsius |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| schneider-bmxdai1604-modicon-x80-digital-input-module-16-channel | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | BMXDAO1605 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
