Product Overview
When your TSX Micro PLC requires additional memory for complex logic or data logging, the Schneider TSXMRP0256P RAM memory card delivers a reliable solution. This accessory provides 256 kilowords of storage, enabling your PLC to handle larger programs and more data points without performance degradation. Designed specifically for the TSX Micro PLC family, this memory card ensures seamless integration and dependable operation.
Technical Specifications Breakdown
Understanding the key parameters of the TSXMRP0256P helps you assess its fit for your application. The memory type is RAM, offering fast read and write speeds for dynamic data handling. With a storage capacity of 256 kilowords, this card supports substantial program and data storage needs. The ambient temperature range of 0 to 40 degrees Celsius ensures stable performance in typical industrial environments. Additionally, the card operates reliably at altitudes up to 1000 meters above sea level and in humidity levels up to 80% non-condensing. Weighing only 0.13 lbs (0.06 kg), it is lightweight and easy to install.
Industry Applications
In manufacturing facilities, the TSXMRP0256P enhances TSX Micro PLCs used for assembly line control. The additional RAM allows for more complex sequencing and real-time data logging, reducing downtime caused by memory limitations. In process control applications, such as water treatment plants, this memory card stores critical alarm and event data, ensuring compliance with regulatory requirements. The card's robust environmental specifications make it suitable for both indoor and sheltered outdoor installations.
Installation & Setup Guidance
Installing the TSXMRP0256P is straightforward. First, power down the TSX Micro PLC completely. Locate the memory card slot on the CPU module. Align the card with the slot and gently push it in until it clicks into place. Ensure the card is seated firmly to avoid connection issues. After installation, power up the PLC and verify the memory expansion is recognized in the programming software. Always handle the card by its edges to prevent electrostatic discharge damage. For optimal performance, install the card in a location within the specified temperature and humidity ranges.
Maintenance & Reliability
To maintain reliable operation, periodically inspect the TSXMRP0256P for signs of physical damage or corrosion. Keep the card and its slot clean and free from dust. The card's non-condensing humidity rating of 80% means it can withstand typical industrial moisture levels, but avoid exposure to liquid spills. Regular backups of PLC programs and data are recommended to prevent loss in case of memory failure. The TSXMRP0256P is classified as a spare part or accessory, meaning it is designed for easy replacement to minimize downtime.
Compatibility & Integration
The TSXMRP0256P is specifically designed for the Schneider Electric TSX Micro PLC series. It integrates directly into the CPU memory slot without additional adapters. This memory card is compatible with all TSX Micro PLC models that support RAM expansion. For best results, verify your PLC model's compatibility by consulting the product documentation. The card's RAM memory type ensures fast data access, making it ideal for applications requiring frequent read/write operations.
Selection Guide & Purchasing Advice
Before purchasing the TSXMRP0256P, confirm that your TSX Micro PLC has an available memory slot and supports RAM expansion. Check the current lifecycle status of the card with SpareTechPLC to ensure availability. As a trusted supplier, SpareTechPLC offers genuine Schneider Electric parts with reliable shipping. When ordering, provide your PLC model number to verify compatibility. This memory card is an excellent choice for expanding your system's memory capacity without replacing the entire PLC.
