Evaluating the 170ADI54050 for Your Automation Needs
When selecting a discrete input base for your industrial control system, you need a component that delivers reliable performance under demanding conditions. The Schneider 170ADI54050, part of the Modicon Momentum series, offers a focused set of features designed for 120V AC discrete input applications. This buyer's guide helps you assess whether this module aligns with your operational requirements.
Key Specifications at a Glance
The 170ADI54050 provides 16 discrete input channels, organized into two groups of eight inputs each. It operates with a discrete input voltage of 120V AC and accepts an input voltage range of 85 to 132V AC. The module supports a network frequency of 47 to 63 Hz, making it suitable for standard industrial power systems.
Environmental resilience is a strong point. The unit functions within an operating temperature range of 0°C to 60°C and can be stored between -40°C and 85°C. It tolerates up to 95% relative humidity without condensation, ensuring dependable operation in humid plant floors. The protective TC treatment adds an extra layer of durability.
Application Scenarios and Use Cases
In a typical packaging line, the 170ADI54050 can monitor limit switches and presence sensors that operate at 120V AC. Its two isolated groups of eight inputs allow you to separate safety-related signals from general status inputs, simplifying troubleshooting and maintenance.
For material handling systems, such as conveyor belts in a distribution center, this discrete input base can handle start/stop commands and jam detection signals. The positive input logic aligns with many standard PLC configurations, reducing integration complexity.
Compatibility and Integration
The 170ADI54050 is designed for the Modicon Momentum automation platform. It integrates seamlessly with Momentum controllers and I/O bases, forming a cohesive system for mid-level automation tasks. The module provides isolation of 1780V AC between groups and between channels and the bus, enhancing signal integrity and protecting against electrical noise.
Business Value and ROI
Choosing the 170ADI54050 can reduce total cost of ownership through its robust environmental ratings and protective treatment, which minimize downtime caused by harsh conditions. The 16-channel density in a compact footprint (5.6 in height, 4.9 in width, 1.9 in depth) saves cabinet space. With a net weight of only 0.626 lb, it is easy to install and replace.
Why Choose SpareTechPLC
SpareTechPLC offers the Schneider 170ADI54050 with reliable sourcing and fast shipping. Our team understands industrial automation spare parts and can help you verify compatibility with your existing system. We provide genuine products backed by manufacturer specifications.
Frequently Asked Questions
What is the input voltage range for the 170ADI54050?
The 170ADI54050 accepts an input voltage range of 85 to 132V AC, with a discrete input voltage rating of 120V AC. This range ensures compatibility with standard industrial AC power systems.
How many channels does this discrete input base have?
It features 16 channels organized into two groups of eight inputs each. This grouping allows flexible wiring and isolation for different signal types.
What is the operating temperature range for the 170ADI54050?
The module operates reliably from 0°C to 60°C and can be stored in temperatures from -40°C to 85°C. It also withstands up to 95% relative humidity without condensation.
Is the 170ADI54050 compatible with Modicon Momentum controllers?
Yes, it is part of the Modicon Momentum automation platform and is designed to work with Momentum controllers and I/O bases. Please verify current lifecycle status and availability with SpareTechPLC before ordering.
