Solving Slot Constraints in Legacy PLC Systems
When expanding a Series 90-30 system, engineers often face the challenge of limited I/O capacity. The IC693CHS391 modular CPU baseplate from GE Fanuc addresses this by providing ten slots in a single chassis. This design allows for one CPU slot and nine I/O slots, giving you room to grow without replacing the entire control system.
Many facilities still rely on Series 90-30 PLCs for critical processes. The IC693CHS391 baseplate enables these systems to accommodate additional modules, extending their useful life. This is especially valuable in industries where upgrading to a new platform would require significant downtime and retraining.
Introducing the IC693CHS391 Modular CPU Baseplate
The IC693CHS391 is a 10-slot modular CPU baseplate manufactured by GE Fanuc as part of the Series 90-30 family. It serves as the backbone for hosting the CPU, I/O modules, and power supply. The baseplate includes a local electronic backplane to power attached modules and an I/O expansion bus port for connecting additional baseplates.
Only one CPU baseplate can be installed per system, making the IC693CHS391 the central hub for control logic. The power supply module occupies an unnumbered slot on the left, while the CPU goes into slot 1. Slots 2 through 10 are reserved for I/O or option modules, giving you flexibility in module selection.
Key Technical Specifications and Their Practical Meaning
The IC693CHS391 operates at 5 Volts DC with a current draw of 420 milliamperes. This low voltage and moderate current make it energy-efficient while providing enough power for the backplane and connected modules. The baseplate supports panel mounting only, secured by screws and washers through the provided mounting holes.
A 25-pin female connector on the right side enables connection to expansion or remote baseplates. The default rack address is rack number 0, which can be modified via programming software. The baseplate also includes a DIP switch for configuration, though standard operation is not supported—meaning it must be used with a CPU or PCI card.
Real-World Applications in Manufacturing
In a typical packaging line, the IC693CHS391 baseplate can host a CPU and multiple I/O modules to control conveyors, sensors, and actuators. The nine I/O slots allow for a mix of digital and analog inputs and outputs, adapting to the specific needs of the line. For example, slot 2 might hold a discrete input module for limit switches, while slot 3 contains an analog output module for variable speed drives.
In a water treatment facility, the baseplate can manage pump sequencing and level monitoring. The expansion port allows connection to up to four or seven additional baseplates, depending on the CPU model. This scalability makes the IC693CHS391 suitable for both small and medium-sized control applications.
Compatibility and Integration with Existing Systems
The IC693CHS391 is designed to work exclusively with Series 90-30 PLCs. It connects to a CPU or to a personal computer using a PCI card. For remote baseplate connections, a cable less than 700 feet in length is required. The baseplate can connect to up to seven CPUs at a time, depending on the CPU model used.
Mounting orientation is flexible—the baseplate can be installed vertically or horizontally to fit the cabinet layout. The environmental temperature must stay within the specified range, and the unit should be kept away from water, dust, and harmful chemicals. The IC693CHS391 is certified by several global environmental and industrial standards, though specific certifications are not listed in the provided data.
Why Choose AutoDCSTech for Your IC693CHS391 Needs
AutoDCSTech specializes in industrial automation spare parts, including the GE IC693CHS391 baseplate. We understand that legacy components can be hard to find, and we maintain a reliable supply to minimize your downtime. Our team can help you verify compatibility and lifecycle status before ordering.
Please verify current lifecycle status and availability with AutoDCSTech before ordering, as the IC693CHS391 is listed as discontinued/obsolete. We are committed to providing quality parts and expert support for your Series 90-30 systems.
What is the voltage requirement for the IC693CHS391 baseplate?
The IC693CHS391 operates at 5 Volts DC. This voltage powers the backplane and the modules installed in the slots.
How many I/O slots does the IC693CHS391 have?
The baseplate has nine I/O slots, numbered 2 through 10. Slot 1 is reserved for the CPU or a specialty module like a FIP Bus Remote I/O scanner.
Can the IC693CHS391 be used as a standalone unit?
No, the IC693CHS391 cannot be used as a single entity. It must be connected to a PLC device or a personal computer using a PCI card to function.
What is the maximum cable length for connecting a remote baseplate?
The cable length must be less than 700 feet when connecting to a remote baseplate. This ensures reliable communication between the baseplates.
