Key Features and Technical Specifications
- 7-inch widescreen TFT display with 800 x 480 pixel resolution.
- 16,777,216 colors for vivid process visualization.
- Analog-resistive touch screen for precise input.
- PROFINET interface with 2-port switch, plus MPI/PROFIBUS DP interface.
- 12 MB configuration memory for extensive applications.
- Windows CE 6.0 operating system pre-installed.
- Configurable with WinCC Comfort V11 or later.
- IP65 front protection and IP20 rear protection.
- Operating temperature range: 0 °C to 50 °C (vertical installation).
- Weight: 1.4 kg without packaging.
One standout feature is the 32 direct keys (touch buttons as S7 input I/O), which allow operators to trigger actions directly from the screen without navigating menus. This capability accelerates routine operations and reduces error rates.
Real-World Applications
In manufacturing environments, the 6AV2124-0GC01-0AX0 excels at machine control and monitoring. For instance, on a packaging line, operators can view real-time production data, acknowledge alarms, and adjust parameters—all from the touchscreen. Furthermore, its support for PROFINET and PROFIBUS ensures seamless integration with Siemens PLCs like S7-300/400 and S7-1200/1500. Additionally, the panel supports Modbus and EtherNet/IP, making it versatile for mixed-vendor plants.
Installation and Mounting Guidance
Mounting the TP700 Comfort is straightforward. The unit supports both portrait and landscape orientations, with a maximum permissible tilt angle of 35° without external ventilation. For optimal performance, install it vertically and ensure the ambient temperature stays within 0 °C to 50 °C. The mounting cutout dimensions are 198 mm by 142 mm, and the overall depth is 63 mm. Use the provided clamps to secure the panel firmly in place.
Maintenance and Reliability Tips
To maintain long-term reliability, periodically inspect the front bezel for dust or debris that could obscure the display. Since the backlight has an MTBF of 80,000 hours at 25 °C, you can expect years of consistent visibility. Also, verify that the 24 V DC supply remains within the permissible range to prevent unexpected shutdowns. For any issues, consult the Siemens manual or contact AutoDCSTech for support.
Compatibility and Integration
The 6AV2124-0GC01-0AX0 integrates with a wide range of controllers. It supports S7-1200, S7-1500, S7-200, S7-300/400, LOGO!, WinAC, SINUMERIK, and SIMOTION. Additionally, it communicates with Allen Bradley (EtherNet/IP, DF1), Mitsubishi (MC TCP/IP, FX), Modicon (Modbus TCP/IP, Modbus), and OMRON (LINK/Multilink). For data exchange, it offers OPC UA Client and Server capabilities. The panel also includes two USB 2.0 ports and two SD card slots for flexible data storage.
Troubleshooting Common Issues
If the display goes blank, first check the 24 V DC supply and ensure it is within 19.2 V to 28.8 V. For communication errors, verify that the PROFINET cable is connected to the correct port and that the IP settings match your network. If the touch screen becomes unresponsive, restart the panel via the power cycle. For persistent problems, refer to the diagnostic information accessible via S7 controllers.
Product Support and Availability
The 6AV2124-0GC01-0AX0 is available from AutoDCSTech. Please verify current lifecycle status and availability before ordering. Our team can assist with technical questions and provide documentation.
Availability & Condition at AutoDCSTech
| Part Number | 6AV2124-0GC01-0AX0 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Germany |
