6FX3002-5CK32-1AD0 3m Preassembled Power Cable

Introduction to the Siemens 6FX3002-5CK32-1AD0 Power Cable

When a motion control system fails, the cause is often a damaged or mismatched power cable. The 6FX3002-5CK32-1AD0 from Siemens provides a reliable, preassembled solution. This cable is designed for S-1FL6 motors in the 200V class, specifically for use with V90 drives in Frame Size D. It is part of the MOTION-CONNECT 300 series, which is known for its robust construction and dependable performance in industrial environments.

This cable comes with a straight connector on the motor side, making installation straightforward. The preassembled design ensures that connections are correctly terminated at the factory, reducing the risk of wiring errors. For engineers and maintenance teams, this means less downtime and more consistent operation.

Key Features and Technical Specifications

The 6FX3002-5CK32-1AD0 is a power cable with a 4x2.5 conductor configuration. This means it has four conductors, each with a cross-section of 2.5 mm², which is suitable for the power requirements of S-1FL6 motors. The cable length is 3 meters, providing flexibility in cabinet and machine layouts.

• Conductor configuration: 4x2.5 mm²
• Length: 3 meters
• Motor-side connector: Straight, with Dmax of 9.7 mm
• Voltage class: 200V (for S-1FL6 motors)
• Series: MOTION-CONNECT 300
• UL rating: Not UL listed (per product data)

This cable is specifically engineered for the V90 drive system with Frame Size D. The 4x2.5 conductor size is critical for delivering the required current to the motor without excessive voltage drop. The straight connector simplifies routing, and the 9.7 mm maximum diameter ensures compatibility with standard cable glands.

Applications and Use Cases

The 6FX3002-5CK32-1AD0It is commonly found in packaging machinery, textile equipment, and robotic systems that use Siemens V90 drives. Because it is a preassembled cable, it is particularly useful for OEMs and panel builders who need a quick, reliable connection between drive and motor.

For example, in a high-speed labeling machine, this cable ensures that the servo motor receives stable power, which is essential for maintaining accurate label placement. In addition, the 3-meter length is often sufficient for connecting motors mounted close to the control cabinet, reducing the need for custom cable fabrication.

Installation and Setup

Installing the 6FX3002-5CK32-1AD0 is straightforward due to its preassembled nature. First, verify that the motor-side connector matches your motor's terminal box. The straight connector is designed for direct insertion, and the Dmax of 9.7 mm ensures a proper fit with standard cable entries.

When routing the cable, avoid sharp bends and ensure that the minimum bend radius is respected. Although the cable is preassembled, it is still important to secure it properly to prevent strain on the connectors. Use cable ties or clamps to fix the cable along its path, and leave some slack near the motor to allow for vibration.

Before powering up the system, double-check that the cable is connected to the correct terminals on both the drive and the motor. A simple continuity test can confirm that all conductors are properly connected.

Maintenance and Reliability

To ensure long-term reliability, inspect the 6FX3002-5CK32-1AD0 periodically for signs of wear, such as cuts, abrasions, or heat damage. Check the connectors for tightness, as vibration can loosen them over time. If the cable is exposed to oil or chemicals, use a cable with appropriate jacketing for those conditions; this standard cable is not specified for harsh chemical exposure.

Because this is a preassembled cable, there are no user-serviceable parts. If damage is detected, replace the cable with a new one to avoid intermittent faults that can cause machine downtime. Keeping a spare cable in inventory is a cost-effective way to minimize production losses.

Compatibility and Integration

The 6FX3002-5CK32-1AD0 is designed for use with Siemens S-1FL6 servo motors in the 200V class, paired with V90 drives in Frame Size D. It is part of the MOTION-CONNECT 300 series, which is a standard for many Siemens motion control systems. This cable is not UL listed, so it may not be suitable for applications requiring UL certification.

For integration, ensure that your drive and motor are both compatible with this cable's specifications. The 4x2.5 conductor size is typically used for motors up to a certain power rating; refer to the motor's datasheet to confirm that this cable meets the current requirements.

Buyer's Guide: Is This Cable Right for You?

When evaluating the 6FX3002-5CK32-1AD0, consider the following factors:

• Motor compatibility: This cable is specifically for S-1FL6 motors with V90 Frame Size D. Verify your motor model.
• Length: The 3-meter length is fixed. If you need a different length, you may need to order a custom cable or use a different part number.
• Connector type: The straight motor-side connector is suitable for most installations, but if you need a right-angle connector, this is not the right choice.
• UL requirement: If your application requires UL-listed components, this cable does not meet that criterion.

By checking these points, you can ensure that this cable meets your system's needs without unnecessary delays.

Product Support and Availability

The 6FX3002-5CK32-1AD0 is available from AutoDCSTech. Please verify current lifecycle status and availability with AutoDCSTech before ordering. For technical questions, refer to the official Siemens documentation or contact AutoDCSTech for assistance.
