6FX8002-2DC10-1BG0 DRIVE-CLiQ Signal Cable | Siemens

Introduction to the 6FX8002-2DC10-1BG0 DRIVE-CLiQ Signal Cable

When signal integrity is critical in motion control, the 6FX8002-2DC10-1BG0 from Siemens provides a reliable pre-assembled connection. This DRIVE-CLiQ cable is engineered for SINAMICS S120 Motor Modules and SINUMERIK 840D sl systems, ensuring seamless communication between drive components.

As an active product (PLM PM300), the 6FX8002-2DC10-1BG0 is readily available for new installations and replacements. Its robust design supports automation environments where data accuracy directly impacts productivity.

Key Features and Technical Specifications

• Pre-assembled type: 6FX8002-2DC10 DRIVE-CLiQ with 24V plug.
• Connector on module side: RJ45 with IP20 protection.
• Connector on motor side: IP67 rated for harsh conditions.
• MOTION-CONNECT 800PLUS: Released for cable lengths up to 75 meters.
• Cable diameter (Dmax): 7.1 mm.
• Length tolerance: +0 / +10 / +6 / +0 meters.

These specifications ensure precise signal transmission and mechanical durability. The IP67 motor-side connector resists dust and water ingress, making the cable suitable for demanding industrial environments.

Applications and Use Cases

For example, in a high-speed bottling plant, the 6FX8002-2DC10-1BG0 connects the motor module to the motor, enabling precise speed and torque control. Its IP67 motor-side connector is particularly beneficial in washdown environments where moisture is a concern.

Installation and Setup

Installing the 6FX8002-2DC10-1BG0 is straightforward due to its pre-assembled nature. Simply connect the RJ45 IP20 end to the module and the IP67 end to the motor. Ensure the cable is routed with a minimum bend radius to avoid stress on the connectors. For lengths up to 75 meters, the cable maintains signal integrity without additional boosters.

Maintenance and Reliability

Regular inspection of the cable and connectors is recommended to prevent wear and tear. Check for any signs of damage, especially at the bend points and connector strain reliefs. The IP67 rating on the motor side provides protection against environmental factors, but periodic verification of the seal integrity is advised. Following Siemens' guidelines ensures long-term reliability.

Compatibility and Integration

The 6FX8002-2DC10-1BG0 is designed for use with SINAMICS S120 Motor Modules and SINUMERIK 840D sl controllers. It supports DRIVE-CLiQ communication, which is Siemens' proprietary interface for drive and control data exchange. This cable is fully compatible with MOTION-CONNECT 800PLUS systems, ensuring optimal performance.

Troubleshooting Common Issues

If communication errors occur, first check the cable connections for secure seating. Verify that the cable length does not exceed 75 meters, as longer runs may degrade signal quality. Inspect the cable for cuts or abrasions, especially in areas with high vibration. If issues persist, consult the Siemens documentation or contact AutoDCSTech for support.

Product Support and Availability

The 6FX8002-2DC10-1BG0 is an active product and available for order. Contact AutoDCSTech for availability and lead times.

Comparison with Alternative Cables

Compared to standard MOTION-CONNECT cables, the 800PLUS series offers enhanced flexibility and robustness. The 6FX8002-2DC10-1BG0 is specifically pre-assembled with a 24V plug, simplifying installation and reducing wiring errors. While other cables may require field assembly, this pre-assembled design saves time and ensures consistent quality.
