Allen-Bradley 22F-V1P6N103 PowerFlex 4M AC Drive, 0.2 kW

Technical Specifications Breakdown

Key parameters for the 22F-V1P6N103 are listed below for quick reference:

Real-World Applications

This drive suits original equipment manufacturers (OEMs) and end users who need reliable speed control in a compact package. Common uses include:

• Conveyor Systems: The 0.2 kW output and 1.6 A current rating handle small conveyor motors, allowing precise speed adjustments for product flow.
• Pumps and Fans: Volts/Hertz control provides smooth acceleration and deceleration, reducing mechanical stress and energy consumption.
• Packaging Machinery: The RS485 interface enables easy integration with PLCs and HMIs, streamlining production line automation.

Installation & Setup Guidance

Proper installation ensures safe and reliable operation. This drive is designed for panel mounting. Ensure adequate clearance for airflow and heat dissipation. Use the built-in Human Interface Module (HIM) to configure parameters such as acceleration, deceleration, and frequency output. The integral keypad allows local parameterization, while the RS485 port supports remote control via a DSI network.

Important: The 22F-V1P6N103 does not include built-in branch short circuit protection. Install appropriate fuses or circuit breakers on the input side. The control wiring must not exceed 30 meters to maintain signal integrity.

Maintenance & Reliability

Regular inspection keeps the drive operating at peak efficiency. Check for dust accumulation on the heatsink and ensure ambient temperature stays within safe limits. The drive includes built-in protection circuits for overvoltage, undervoltage, motor stall, phase-to-ground faults, short circuits, heatsink overtemperature, overcurrent, and overload. These features help prevent damage and extend equipment life.

Compatibility & Integration

The built-in RS485 port supports standard Modbus RTU communication. For advanced networking, optional protocols include BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, and ControlNet. This flexibility allows the drive to fit into diverse automation architectures.

Selection Guide & Purchasing Advice

When selecting a replacement or new drive, verify your motor's voltage and current requirements. The 22F-V1P6N103 operates on 100-120VAC single-phase input and delivers three-phase output up to 460VAC. For expert guidance and competitive pricing, contact AutoDCSTech. We specialize in industrial automation parts and can help you find the right solution.

Please verify current lifecycle status and availability with AutoDCSTech before ordering.
