Technical Specifications Breakdown
Key parameters for the 20F11NC060JA0NNNNN are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F11NC060JA0NNNNN |
| Rated Output | 30 kilowatts |
| Rated Phase | 3-phase |
| Voltage Rating | 400 Volts AC and 540 Volts DC |
| Frequency Tolerance | 47 to 63 Hertz |
| Rated Horsepower | 40 horsepower |
| Ambient Operating Temperature | 0 to 40°C (non-condensing) |
| Storage Temperature | -40 to 70°C (non-condensing) |
| Weight | 50.00 lbs (22.68 kg) |
Industry Applications
The 30-amp output and 40-horsepower rating make it suitable for medium-duty industrial machinery. Its embedded I/O simplifies integration into existing control networks, reducing installation time.
Installation & Setup Guidance
Mount the drive in a clean, dry location with adequate airflow for forced air cooling. Ensure the AC input voltage matches the 400 VAC rating and that the DC terminals are connected per the manual. The included default common mode (CM) cap connection jumper must be properly installed to avoid ground loops. No Human Interface Module is included, so configure via a connected HIM or software.
Maintenance & Reliability
Inspect the air cooling vents regularly to prevent dust buildup, which can reduce cooling efficiency. Operate within the 0 to 40°C ambient temperature range to ensure long life. The drive’s protective features—including AC input overvoltage/undervoltage trip, ground fault trip, short circuit trip, bus overvoltage/undervoltage trip, and drive overcurrent trip—help prevent damage from electrical faults. Store the unit in a non-condensing environment between -40 and 70°C when not in use.
Compatibility & Integration
This PowerFlex 753 drive uses Sine Coded Pulse Width Modulation (PWM) control with a programmable carrier frequency, allowing fine-tuning for motor compatibility. The built-in filter and internal braking transistor enhance performance in applications requiring rapid deceleration. The drive is designed for 3-phase systems and accepts both 400 VAC and 540 VDC inputs.
Selection Guide & Purchasing Advice
When selecting a drive, verify that the voltage, current, and power ratings match your motor and application. For lifecycle status and availability, contact AutoDCSTech before ordering. Our team can help confirm compatibility and provide support for your industrial automation needs.
Availability & Condition at AutoDCSTech
| Part Number | 20F11NC060JA0NNNNN |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
