Product Overview
When a control system demands reliable discrete output switching, the GE Fanuc IC200MDL740 Discrete Output Module delivers consistent performance. This 16-point output module is part of the Versamax series and uses positive logic for straightforward integration. Designed for industrial environments, it provides 16 sourcing outputs in a single group, simplifying wiring and reducing panel space. The module features hot insertion capability, allowing replacement without disturbing field wiring—a key advantage for maintenance engineers seeking minimal downtime.
Technical Specifications
- Part Number: IC200MDL740
- Brand: GE Fanuc
- Series: Versamax
- Product Description: Discrete Output Module
- Module ID: FFFF8080
- Number of Points: 16 Outputs
- Number of Groups: 1
- Output Voltage: 10.2 to 30 VDC, 12/24 VDC nominal
- Group to Group Isolation: None
- Point to Point Isolation: None
- LED Indicators: One LED per point, and "OK" and "FLD PWR" LEDs
- Backplane Current Consumption: 5 Volts, 45 milliamps
- Fuse: None
- External Power Supply: 10.2 to 30 VDC, 12/24 VDC nominal
These specifications confirm the module operates on standard 12/24 VDC control voltages, making it compatible with many industrial sensors and actuators. The single-group configuration reduces complexity, while the per-point LEDs simplify troubleshooting.
Industry Applications
In manufacturing lines, the IC200MDL740 controls solenoid valves, motor starters, and indicator lights. For example, in a packaging machine, it manages 16 discrete outputs to sequence conveyor belts and pneumatic actuators. The 10.2 to 30 VDC range ensures stable operation even with voltage fluctuations common in industrial settings. Maintenance engineers appreciate the hot insertion feature, which allows module replacement without powering down the entire rack—critical for continuous production processes.
Installation & Setup Guidance
Mount the IC200MDL740 in a Versamax rack using one of the three available carrier types. Ensure the backplane provides 5 VDC at 45 mA. Connect the external power supply (10.2 to 30 VDC, 12/24 VDC nominal) to the DC+ and DC- terminals. For inductive loads, install an external suppression circuit across the load or at each output point to protect the module. Use a shorting bar with adequate current capacity on the B terminal if additional bused terminals are needed. The module supports hot insertion, so you can install or replace it without removing field wiring.
Maintenance & Reliability
Routine inspection of the IC200MDL740 focuses on the LED indicators: one per point plus "OK" and "FLD PWR". A lit "OK" LED confirms proper backplane communication; "FLD PWR" indicates external power is present. Since the module has no internal fuse, verify the external power supply is within 10.2 to 30 VDC. The compact design and hot insertion reduce maintenance time, aligning with cost-saving goals. Regularly check for loose connections or signs of overheating, especially in high-vibration environments.
Compatibility & Integration
The IC200MDL740 integrates seamlessly with GE Fanuc Versamax PLC systems. It communicates via the backplane using standard Versamax protocols. The module works with any Versamax CPU and compatible racks. For network integration, use the appropriate Versamax communication modules. The positive logic output type matches most industrial discrete loads.
Selection Guide & Purchasing Advice
Before ordering the IC200MDL740, verify your system's backplane voltage and current capacity (5 VDC, 45 mA). Ensure your external power supply meets the 10.2 to 30 VDC range. The module requires a carrier; choose from the three available types based on your wiring needs. Contact SpareTechPLC for current availability and lifecycle status—this module may be discontinued, so confirm stock before ordering. SpareTechPLC offers genuine GE Fanuc parts with reliable support.
Frequently Asked Questions
Q: What is the output voltage range of the IC200MDL740?
A: The output voltage range is 10.2 to 30 VDC, with a nominal of 12/24 VDC.
Q: Does the IC200MDL740 require an external fuse?
A: No, the module has no internal fuse. Use an external suppression circuit for inductive loads.
Q: How many output points does the IC200MDL740 have?
A: It has 16 discrete outputs in one group.
Q: Can I replace the IC200MDL740 without powering down the system?
A: Yes, the module supports hot insertion, allowing replacement without interrupting operation.
Q: What do the LED indicators on the IC200MDL740 show?
A: One LED per point indicates output status, plus "OK" for backplane communication and "FLD PWR" for external power.
