Product Overview
The Honeywell MSOX3034A Mixed Signal Oscilloscope delivers the measurement power needed for today's complex embedded designs. With 350 MHz bandwidth and 4 analog plus 16 digital channels, this instrument lets you capture and correlate analog and digital signals simultaneously. Whether you are debugging a mixed-signal control system or validating timing margins, the MSOX3034A provides the visibility you need to find faults fast.
Technical Specifications Breakdown
Key parameters for the MSOX3034A are listed below for quick reference:
| Feature | Specification |
|---|---|
| Bandwidth | 350 MHz |
| Analog Channels | 4 |
| Digital Channels | 16 |
| Memory Depth | Up to 4 Mpts |
| Update Rate | 1,000,000 waveforms/sec |
| Display | 8.5-inch WVGA |
| Included Probe | N2890A Passive probe 500 MHz, 10:1 attenuation (1 per channel) |
| Included Cable | N2756-60001 16 digital channel MSO cable |
Industry Applications
In industrial automation, engineers use it to verify PLC I/O timing, analyze sensor outputs alongside encoder pulses, and debug communication buses. The 1,000,000 waveforms/sec update rate quickly reveals intermittent glitches that slower scopes miss. With 4 Mpts memory, you can capture long time windows to analyze complex protocol sequences without losing resolution.
Installation & Setup Guidance
When setting up the MSOX3034A, first connect the included N2890A passive probes to the analog channels. Attach the N2756-60001 MSO cable to the digital input connector. Ensure all connections are secure before powering on. Use the built-in help and interface language support (English, Japanese, simplified Chinese, traditional Chinese, Korean, German, French, Spanish, Russian, Portuguese, Italian, Thai, and Polish) to configure the instrument for your local environment. Calibrate the probes to match the 10:1 attenuation for accurate measurements.
Maintenance & Reliability
The MSOX3034A comes with a 3-year warranty and a 2-year calibration interval. To maintain accuracy, follow the recommended calibration schedule. Keep the oscilloscope in a clean, dry environment to prevent dust buildup on connectors and the display. Periodically inspect probes and cables for damage. The included certificate of calibration ensures your measurements meet specified tolerances.
Compatibility & Integration
The MSOX3034A is fully upgradeable. You can add bandwidth, memory, a 20 MHz arbitrary waveform generator, a 3-digit voltmeter, serial trigger and analysis, segmented memory, and mask testing at any time. This flexibility allows the instrument to adapt to changing measurement needs without purchasing a new scope. The 16 digital channels integrate with the 4 analog channels for mixed-signal analysis.
Selection Guide & Purchasing Advice
When selecting a mixed signal oscilloscope, consider bandwidth, channel count, and memory depth. The MSOX3034A offers 350 MHz bandwidth, 4 analog plus 16 digital channels, and up to 4 Mpts memory, making it suitable for a wide range of embedded and industrial applications. AutoDCSTech provides genuine Honeywell parts and expert support. Contact AutoDCSTech to verify current lifecycle status and availability before ordering. Our team can help you choose the right oscilloscope for your specific requirements.
Troubleshooting & Common Issues
If the display shows no signal, check that the probe is connected to the correct channel and that the input impedance is set appropriately. For digital channels, ensure the MSO cable is firmly attached. If the update rate seems slow, verify that the memory depth setting is not excessively high. For intermittent signal issues, use the mask testing feature to automatically detect anomalies. Always refer to the user manual for detailed troubleshooting steps.
Availability & Condition at AutoDCSTech
| Part Number | MSOX3034A |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
