Schneider 170BAI03600 Modicon Momentum Analog Input Module 8-Channel

Product Overview

The Schneider Electric 170BAI03600 is a reliable analog input module from the Modicon Momentum series, designed for precise signal measurement in industrial automation.

Technical Specifications Breakdown

Key parameters for the 170BAI03600 are listed below for quick reference:

Industry Applications

In process control systems, the eight channels allow simultaneous monitoring of multiple sensors, such as temperature or pressure transmitters. The 24 V DC operation ensures compatibility with standard industrial power supplies, reducing installation complexity. For manufacturing lines, the module's ability to function at temperatures up to 60 degrees Celsius and humidity up to 80% RH makes it suitable for harsh factory floors.

Installation & Setup Guidance

When installing the 170BAI03600, ensure the power supply is within the specified 24 V DC range and that the current draw does not exceed 1 A. Mount the module in a clean, dry location within the ambient temperature range of 0 to 60 degrees Celsius. Avoid condensation by maintaining humidity below 80% RH. For altitude applications, confirm the site is below 1000 meters above sea level to guarantee reliable operation. Always follow Schneider Electric's wiring guidelines for analog input connections.

Maintenance & Reliability

To maintain long-term reliability, periodically inspect the module for dust accumulation or signs of corrosion, especially in humid environments. The non-condensing humidity tolerance of up to 80% RH helps protect against moisture damage. Verify that the ambient temperature remains within the 0 to 60 degrees Celsius range during operation. Regular checks of the 24 V DC supply voltage and current levels ensure consistent performance.

Compatibility & Integration

The 170BAI03600 is part of the Modicon Momentum series, designed for seamless integration with Schneider Electric's automation platforms. Its 24 V DC operation aligns with common industrial control systems, simplifying wiring and reducing power supply diversity. The eight analog input channels support various sensor types, enhancing system flexibility.

Selection Guide & Purchasing Advice

When selecting the 170BAI03600, consider the number of analog input points required; eight channels suit medium-density applications. Verify that the 24 V DC supply is stable and capable of delivering 1 A per module. For replacement or new installations, AutoDCSTech offers this module with verified authenticity. Please confirm lifecycle status and availability with AutoDCSTech before ordering.
