Technical Specifications Breakdown
Key parameters for the 170PNT16020 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | Communication Adaptor |
| Communication Protocol | Modbus Plus |
| Transmission Rate | 1 Mbit/s |
| Access Methods Supported | Token Bus, Peer To Peer |
| Operating Temperature | 0 to 40 degrees Celsius |
| Storage Temperature | 0 to 50 degrees Celsius |
| Maximum Relative Humidity (Operation/Storage) | 80% (non-condensing) |
| Maximum Operating/Storage Altitude | 1000 meters above sea level |
| Weight | 0.25 lbs (0.11 kg) |
Industry Applications
Discrete Manufacturing Networks
The token bus access method ensures deterministic data transfer, critical for synchronized assembly operations.
Process Control Retrofit Projects
For older process plants upgrading their control architecture, the 170PNT16020 provides a cost-effective bridge. Its peer-to-peer capability allows direct data sharing between remote I/O racks without a dedicated master controller, reducing wiring and programming complexity.
Material Handling Systems
In conveyor and sortation systems, the 1 Mbit/s transmission rate supports real-time status updates from multiple nodes. The clean indoor environment requirement aligns well with typical warehouse conditions, ensuring long-term reliability.
Installation & Setup Guidance
Mount the communication adaptor in a clean, dry enclosure free from corrosive substances. Ensure the ambient temperature stays within 0 to 40 degrees Celsius during operation. Connect the Modbus Plus network cable to the dedicated port, observing proper termination and grounding practices. Verify that the token bus or peer-to-peer access method is configured correctly in the network master. The unit is lightweight (0.25 lbs), so standard DIN-rail mounting is straightforward.
Maintenance & Reliability
Periodically inspect the adaptor for dust accumulation and ensure the relative humidity remains below 80% non-condensing. Check cable connections for tightness and signs of wear. Because this device is designed for clean indoor use, avoid exposure to chemicals or excessive vibration. Storage conditions should stay between 0 and 50 degrees Celsius.
Solving Network Integration Challenges in Industrial Automation
In a typical manufacturing plant, integrating legacy equipment with newer control systems often creates communication bottlenecks. The Schneider 170PNT16020 Modicon Momentum communication adaptor directly addresses this challenge by providing a reliable Modbus Plus interface. This component enables seamless peer-to-peer and token bus data exchange, ensuring that critical production data flows without interruption.
Compatibility & Integration
The 170PNT16020 is part of the Schneider Modicon Momentum series and uses the Modbus Plus protocol. It supports both token bus and peer-to-peer access methods, making it compatible with a wide range of Modicon PLCs and third-party devices that adhere to the Modbus Plus standard. Integration into existing networks requires minimal configuration, typically through the network master's programming software.
Selection Guide & Purchasing Advice
When selecting a communication adaptor for your Modbus Plus network, verify that the transmission rate (1 Mbit/s) and access methods meet your application's requirements. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 170PNT16020 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
