Optimizing Control Costs with the Schneider 171CCC96030C Processor Adaptor
In industrial automation, balancing performance with budget is critical. The Schneider Electric 171CCC96030C, part of the Modicon Momentum series, offers a cost-effective solution for discrete and process control. This processor adaptor integrates an Ethernet port and runs at 50 MHz, providing reliable network communication without the premium of high-end controllers. Its 512 KB flash and 512 KB RAM ensure sufficient memory for typical applications, reducing the need for costly expansions.
Technical Specifications Breakdown
Key parameters for the 171CCC96030C are listed below for quick reference:
| Feature | Specification |
|---|---|
| Processor Name | X 86 based (INTEL, AMD) |
| Clock Frequency | 50 MHz |
| Flash Memory | 512 KB |
| RAM | 512 KB |
| Communication Port Protocol | Ethernet |
| Ethernet Service | I/O scanning, Modbus TCP messaging |
| Discrete I/O Processor Capacity | 8192 I/8192 O |
| Register I/O Processor Capacity | 26048 I/26048 O |
| [Us] Rated Supply Voltage | 5.0 V DC +/-5 % |
| Operating Temperature | 0 to 40 degrees Celsius |
| Net Weight | 0.093 lb(US) (0.042 kg) |
Industry Applications and Cost Benefits
Its support for Modbus TCP messaging reduces integration costs by enabling direct communication with SCADA or MES systems. The 50 MHz processor handles 1 ms per 1K instruction, ensuring timely responses for most discrete control loops, which minimizes downtime and waste.
Installation and Setup Guidance
Mount the processor adaptor on a Modicon Momentum I/O base, which supplies the 5.0 V DC power. Ensure the environment is clean, indoor, and free from corrosive chemicals. Operating altitude is up to 2000 meters, but for optimal reliability, keep below 1000 meters as per the main specs. Use Concept V2.6 or ProWORX 32 for configuration. The Ethernet port supports I/O scanning and Modbus TCP; set IP addresses carefully to avoid conflicts.
Maintenance and Reliability
Inspect the unit periodically for dust accumulation, especially in environments up to 80% RH. The conformal coating (Humiseal 1A33) protects against moisture, but avoid condensation. Storage temperature ranges from -40 to 85 °C, so spare units can be kept in varied conditions. With no moving parts, the 171CCC96030C offers long service life, reducing total cost of ownership.
Compatibility and Integration
This processor adaptor is part of the Modicon Momentum platform and supports Transparent Ready Class B10. It integrates with I/O bases and other Momentum modules. The Ethernet port enables seamless connection to plant networks, while Modbus TCP messaging allows easy data exchange with third-party devices. The 16-bit word length and 128 I/O words per drop (Concept) ensure efficient data handling.
Selection Guide and Purchasing Advice
When selecting the 171CCC96030C, confirm your I/O requirements fit within the 8192 discrete I/O capacity. For projects needing cost-efficient Ethernet control, this model is ideal. AutoDCSTech offers this processor adaptor with fast shipping. Verify lifecycle status before ordering, as availability may vary. Contact AutoDCSTech for current stock and pricing.
Availability & Condition at AutoDCSTech
| Part Number | 171CCC96030C |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
