Technical Specifications Breakdown
Key parameters for the 171CCC96020C are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | Processor Adaptor |
| Product Line | Modicon Momentum |
| Clock Frequency | 50 MHz |
| CPU Architecture | x86-based |
| Communication Ports | 1 Ethernet, 1 I/O bus |
| Communication Protocol | Ethernet (Modbus TCP, I/O scan) |
| Memory Type | 512 KB Flash, 544 KB RAM |
| Supply Voltage | 5 VDC ±5% |
| Operating Temperature | 0°C to 60°C |
| I/O Capacity (Discrete) | 8192 In / 8192 Out |
| I/O Capacity (Registers) | 26048 In / 26048 Out |
Industry Applications Driving ROI
Discrete Manufacturing Lines
With 8192 discrete inputs and outputs, the 171CCC96020C efficiently manages high-speed packaging or assembly machines. Using Modbus TCP over Ethernet reduces cabling costs and simplifies network topology, lowering total installed cost.
Process Control with Register Data
The 24 KB data memory ensures reliable storage of critical process parameters.
Remote I/O Scanning
The I/O bus port enables cost-effective expansion by connecting remote Momentum I/O bases. This reduces the need for multiple controllers, cutting hardware and maintenance expenses.
Installation and Setup Guidance
Mount the 171CCC96020C directly onto a Momentum I/O base. Ensure the supply voltage is 5 VDC ±5% to avoid damage. Use the Ethernet port for initial configuration via Modbus TCP. For I/O scanning, configure the I/O bus parameters in your programming software (LL984). Verify that the operating environment stays within 0°C to 60°C to maintain reliability.
Maintenance and Reliability
The conformal coating (Humiseal 1A33) protects against moisture and dust, extending service life in harsh environments. Inspect the unit annually for signs of corrosion or physical damage. Keep the ventilation slots clear to prevent overheating. The 512 KB Flash memory retains programs during power loss, reducing downtime.
Cost-Effective Control with the Schneider 171CCC96020C Processor Adapter
In industrial automation, balancing performance with operational costs is critical. The Schneider Electric Modicon Momentum 171CCC96020C processor adapter delivers robust processing power without unnecessary expense, making it a smart choice for mid-range control applications. Its x86-based architecture and 50 MHz clock frequency provide reliable execution of logic programs, while the integrated Ethernet port with Modbus TCP protocol reduces wiring and integration costs.
Compatibility and Integration
The Ethernet port supports Modbus TCP, allowing connection to SCADA systems, HMIs, and other controllers. The 16-bit word length ensures compatibility with legacy and modern devices.
Selection Guide and Purchasing Advice
When selecting a processor adapter, consider your I/O count and communication needs. At AutoDCSTech, we stock this model and can advise on lifecycle status. Please verify current availability with AutoDCSTech before ordering.
Troubleshooting and Common Issues
If the controller fails to communicate, check the Ethernet cable and verify that the Modbus TCP settings match your network. For I/O bus errors, ensure the base module is properly seated. If the unit does not power on, confirm that the 5 VDC supply is within ±5% tolerance. For persistent issues, consult the Momentum user manual.
Availability & Condition at AutoDCSTech
| Part Number | 171CCC96020C |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
