TSX-P57-204M: Modicon Premium Unity Processor
The TSX-P57-204M is the Modicon Premium Unity Processor covered on this page. The attribute that decides whether it fits the existing installation without modification is Internal RAM 160 kB.
The reason to specify this exact variant is modicon premium unity processor. A processor or controller is selected on memory, scan time and platform compatibility before anything else. modicon premium unity processor sets how much programme fits, how fast the logic executes and which I/O and networks the unit can host — the three things that decide whether an existing application migrates without a rewrite. Confirming Internal RAM 160 kB against the installed controller family is the check that prevents a processor that boots but cannot run the existing project.
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Brand | Schneider |
| Part Number | TSX-P57-204M |
| Product Line | Modicon |
| Part Number | TSX-P57-204M |
| Weight | 0.69 lbs (0.31 kg) |
| Number of Racks | 16 (4/6/8 slots), 8 (12 slots) |
| Discrete I/O Capacity | 1024 |
| Analog I/O Capacity | 80 |
| Application Specific Channels | 24 |
| Process Control Channels | 10 (up to 30 simple loops) |
| Communication Module Capacity | 4 |
| Memory | Internal RAM 160 kB |
| Execution Time | 0.19 µs Boolean |
| Current Consumption | 850 mA |
| IP Rating | IP20 |
| Ambient Temperature | 32…140 °F (0…60 °C) |
| Storage Temperature | -13…158 °F (-25…70 °C) |
| Relative Humidity | 10…95% (operation) |
| Altitude | 0...2000 m |
| Standards | UL 508, CSA C22.2 No 142, IEC 61131-2 |
| Certifications | LR, DNV, ABS, GL, RINA, BV, RMRS |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| schneider-140cpu65160c-modicon-quantum-unity-processor-266-mhz | confirm the configuration against your installation |
| schneider-170adm85010-modicon-momentum-i-o-module-for-industrial-control | confirm the configuration against your installation |
| schneider-140qsm67160-modicon-quantum-hot-standby-unit | confirm the configuration against your installation |
| schneider-140qucmoe-universal-communications-module-for-modicon-quantum | confirm the configuration against your installation |
| schneider-140x816-modbus-plus-floating-point-option-adapter-overview | confirm the configuration against your installation |
| schneider-140xca71706-modicon-quantum-backplane-expander-cable-2m | confirm the configuration against your installation |
| schneider-140xca71709-modicon-quantum-backplane-expander-cable-3m | confirm the configuration against your installation |
| schneider-140xcp40200-rear-rail-bracket-for-modicon-quantum-systems | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | TSX-P57-204M |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
