What Is the TSXP574634M?
When your automation system demands reliable, scalable control, the Schneider TSXP574634M Unity processor delivers. Part of the TSX Micro PLCs series, this module supports up to eight racks with twelve slots each or sixteen racks with configurations of four, six, or eight slots. This flexibility makes it ideal for applications requiring extensive I/O and modular expansion.
Technical Specifications Breakdown
The TSXP574634M consumes 1880 mA at 5 V DC and comes in a double module format. Its processing speed includes a Boolean execution time of 0.039-0.057 µs without a PCMCIA card and 0.048-0.057 µs with one. Floating-point operations run at 0.55-0.63 µs regardless of the card. System overhead is minimal: 0.08 ms for fast tasks and 1 ms for master tasks. Internal RAM reaches 2048 kB for programs and 440 kB for data with a PCMCIA card, or 440 kB combined without it. A PCMCIA card adds 16384 kB of additional data storage.
Industry Applications
In manufacturing lines, the TSXP574634M handles up to 2040 discrete I/O points and 256 analog I/O points, making it suitable for complex machine control and process automation. For example, in a packaging facility, it can manage multiple conveyor zones and sensors simultaneously. Its fast task overhead of 0.08 ms ensures rapid response to critical events, reducing downtime.
Installation & Setup Guidance
Mount the TSXP574634M in a suitable enclosure with proper ventilation. Connect the power supply to the 5 V DC input, ensuring the current draw does not exceed 1880 mA. Use the Ethernet TCP/IP RJ45 port for network integration, the USB port (12 Mbit/s) for programming, and the serial link female mini-DIN RS485 (19.2 kbit/s) for legacy devices. Configure the processor using Unity Pro software. Verify all connections before powering on.
Maintenance & Reliability
Regularly inspect the TSXP574634M for dust accumulation and ensure ambient temperature stays between 32 and 140 °F (0 to 60 °C). The protective treatment TC helps resist environmental stress. Check the three status LEDs: green RUN for normal operation, red ERR for processor or system faults, and red I/O for module or configuration errors. Promptly address any fault indications to maintain system reliability.
Compatibility & Integration
The TSXP574634M integrates seamlessly with the Modicon Premium automation platform and supports Unity Pro software. It communicates via Ethernet TCP/IP (10BASE-T/100BASE-TX), USB, and RS485 serial link. It works with up to 4 communication modules and handles up to 64 application-specific channels. This processor is also compatible with Concept software and Transparent Ready features.
Buying Guide
Before purchasing the TSXP574634M, verify your system's rack configuration and I/O requirements. Ensure you have the correct PCMCIA card if additional memory is needed. SpareTechPLC offers this Unity processor with fast shipping and expert support. Contact us to confirm availability and lifecycle status before ordering.
