IC693ALG392 Analog Output Module Guide for Series 90-30

Understanding the IC693ALG392 Analog Output Module

When precise analog control is required in industrial automation, the GE Fanuc IC693ALG392 provides a reliable solution. This Series 90-30 module delivers eight single-ended output channels, supporting both voltage and current signals. Engineers often use it to modulate variable frequency drives, control valves, and positioners, ensuring smooth process regulation.

The IC693ALG392 is factory calibrated and offers configurable resolution of 15 or 16 bits, depending on the selected output range. It requires an isolated 24 VDC power supply connected directly to its terminal block, plus 5 VDC from the PLC backplane. This design simplifies wiring and integration into existing Series 90-30 or RX3i systems.

Technical Specifications and Performance

The IC693ALG392 supports voltage outputs of 0 to +10 volts (unipolar) and -10 to +10 volts (bipolar), as well as current outputs of 0 to 20 mA and 4 to 20 mA. Each channel updates every 8 milliseconds, providing responsive control for dynamic processes. Resolution at 4-20 mA is 0.5 microamps, while at 0-20 mA it is 0.625 microamps. For voltage ranges, resolution is 0.312 mV for both 0-10 V and -10 to 10 V.

Internal power consumption is 110 mA at 5 VDC from the backplane and 315 mA at 24 VDC from the user-supplied source. The module fits any slot in an RX3i chassis, with no limit on the number of instances per rack, subject to the controller's analog data capacity. This flexibility makes it suitable for systems requiring multiple analog outputs.

Applications in Modern Manufacturing

In a typical packaging line, the IC693ALG392 can control servo drives or proportional valves to adjust conveyor speed or tension. Its fast 8 ms update rate ensures precise synchronization. In water treatment plants, the module outputs 4-20 mA signals to regulate chemical dosing pumps, maintaining consistent treatment quality.

Another common use is in HVAC systems, where the module drives variable frequency drives for fans or compressors. The bipolar voltage range allows bidirectional control, such as positioning actuators in both directions. These applications benefit from the module's configurable resolution, which balances accuracy and noise immunity.

Comparison with Similar Analog Output Modules

Compared to older Series 90-30 analog output modules, the IC693ALG392 offers higher resolution (0.312 mV per count for voltage) and a wider current range (0-20 mA and 4-20 mA). Many competing modules in the same category provide only 12-bit resolution, whereas the IC693ALG392 achieves 15 or 16 bits. This higher resolution reduces quantization error, improving control precision in demanding applications.

However, the IC693ALG392 requires an external 24 VDC supply, unlike some modules that draw all power from the backplane. This adds a wiring step but ensures stable output signals even under heavy load. For systems already using 24 VDC, this is not a drawback. The module's compatibility with RX3i racks also extends its lifespan, as it can be used in newer platforms.

Frequently Asked Questions About the IC693ALG392

What voltage and current ranges does the IC693ALG392 support?

The module supports voltage outputs of 0 to +10 volts (unipolar) and -10 to +10 volts (bipolar), plus current outputs of 0 to 20 mA and 4 to 20 mA. Each channel is individually configurable for these ranges.

How is the IC693ALG392 powered?

It requires an isolated 24 VDC supply connected directly to its terminal block, plus 5 VDC from the PLC backplane. Internal power consumption is 110 mA at 5 VDC and 315 mA at 24 VDC.

Can the IC693ALG392 be used in an RX3i system?

Yes, the module fits any slot of an RX3i chassis. There are no limits on the number of instances per rack, but the total depends on the analog data capacity of the specific RX3i controller.
