6FX3002-5CK01-1AD0 3m MOTION CONNECT 300 Cable

Introduction to the 6FX3002-5CK01-1AD0

When you need a reliable motor cable for your Siemens drive system, the 6FX3002-5CK01-1AD0 delivers the performance your application demands. This MOTION CONNECT 300 cable is engineered for precise power transmission in industrial automation environments. With a length of 3.0 meters and a 4x0.75 mm² conductor cross-section, it provides a robust connection for servo motors and drives.

As part of the Siemens MOTION CONNECT family, this cable is designed to meet the rigorous requirements of modern machinery. Whether you are retrofitting an existing system or building a new one, the 6FX3002-5CK01-1AD0 offers the durability and electrical performance you need.

Key Features & Technical Specifications

The 6FX3002-5CK01-1AD0 is built to handle demanding industrial conditions. Here are the core specifications that make it a dependable choice:

• Number of cores: 4x0.75 mm² – provides balanced power delivery.
• Test voltage (rms): 4000V – ensures insulation integrity under stress.
• Rated voltage UO/U: 300V/500V per EN 50395 – suitable for standard industrial power systems.
• Smallest bending radius (fixed): 6 x diameter – allows compact routing in tight spaces.
• Smallest bending radius (flexible): 155 mm – supports dynamic applications with minimal stress.
• Number of bends (max): 100,000 – long service life in flexing applications.
• Tensile stress (fixed): 50 N/mm² – withstands high pulling forces during installation.
• Tensile stress (flexible): 20 N/mm² – maintains performance in moving cables.
• Torsional stress: Absolute 30°/m – handles twisting without damage.
• Connection type: Straight connector (fixed cable outlet direction) – simplifies wiring.
• Length: 3.0 m – ready-to-use length for many installations.

These specifications ensure that the 6FX3002-5CK01-1AD0 meets the electrical and mechanical demands of modern servo systems.

Applications & Use Cases

Common applications include CNC machines, packaging equipment, and robotic systems where precise motion control is essential. Its flexible design allows for use in cable tracks and moving parts, while the robust construction ensures reliable operation in harsh environments.

For example, in a high-speed packaging line, the cable's ability to withstand 100,000 bends ensures long-term reliability, reducing downtime and maintenance costs. Similarly, in robotic arms that experience torsional stress, the 30°/m rating provides the flexibility needed without compromising performance.

Installation & Setup

Proper installation is crucial to maximize the performance of the 6FX3002-5CK01-1AD0. When routing the cable, always respect the minimum bending radius—6 times the cable diameter for fixed installations and 155 mm for flexible applications. Avoid exceeding the maximum tensile stress of 50 N/mm² (fixed) or 20 N/mm² (flexible) during pulling.

For flexible installations, ensure that the cable is not twisted beyond the rated 30°/m. Use appropriate strain relief at connection points to prevent mechanical stress on the connector. The straight connector with fixed cable outlet direction simplifies routing, but verify that the outlet direction aligns with your installation layout.

Maintenance & Reliability

To ensure long-term reliability, inspect the 6FX3002-5CK01-1AD0 periodically for signs of wear, especially in areas where the cable flexes or moves. Check for cuts, abrasions, or kinks that could compromise insulation integrity. Although the cable is rated for 100,000 bends, environmental factors such as extreme temperatures or chemical exposure can affect its lifespan.

Regularly verify that the connector is securely fastened and free from corrosion. If the cable is used in a high-vibration environment, consider additional clamping to reduce stress. By following these simple maintenance practices, you can extend the service life of the cable and avoid unexpected failures.

Compatibility & Integration

The 6FX3002-5CK01-1AD0 is part of the Siemens MOTION CONNECT 300 series, designed to work with Siemens drive systems. It is compatible with a wide range of Siemens servo motors and converters that use the same connector type. When integrating this cable into your system, ensure that the voltage rating (300/500V) matches your drive's output voltage.

For systems requiring longer cable lengths, consult the Siemens documentation for maximum allowable lengths based on drive type and cable cross-section. The 4x0.75 mm² conductor size is suitable for many standard applications, but always verify that it meets the current requirements of your motor.

Troubleshooting & Common Issues

One common issue with motor cables is intermittent connection due to loose connectors. If you experience erratic motor behavior, first check that the 6FX3002-5CK01-1AD0 connector is fully seated and locked. Another issue is cable damage from excessive bending or pulling. Inspect the cable for any visible damage, especially near the connector and in areas where it moves.

If the cable is subjected to torsional stress beyond its rating, it may develop internal breaks. To avoid this, ensure that the cable is installed with proper strain relief and that moving parts do not twist it more than 30°/m. If problems persist, refer to the Siemens installation guidelines or contact AutoDCSTech for technical support.

Product Support & Availability

The 6FX3002-5CK01-1AD0 is available from AutoDCSTech, your trusted source for industrial automation parts. We stock this cable and can ship it promptly to minimize your downtime. For technical inquiries or to place an order, contact our team today.
