Product Introduction
When precise motion control is critical in CNC machining, the FANUC A06B-6096-H301 Servo Amplifier Module delivers reliable performance. This unit is part of the FANUC A06B series and is designed to manage up to three axes simultaneously. It operates within a temperature range of 0 to 40 degrees Celsius, making it suitable for typical industrial environments. With a power rating of 1.85 kW, this module provides the necessary drive for demanding machining tasks.
Technical Specifications Breakdown
The A06B-6096-H301 accepts an input voltage of 283-325V and delivers a maximum output voltage of 230V. Each of the three axes (L, M, N) can supply an output current of 3 Amps, ensuring consistent power to connected servo motors. The module weighs 22.00 lbs (9.98 kg) and can withstand vibration up to 5G, as well as altitudes up to 1000 meters above sea level. These specifications make it a robust choice for various CNC applications.
Industry Applications
This servo amplifier module excels in multi-axis CNC milling, turning, and routing operations. For example, in a three-axis milling machine, the A06B-6096-H301 coordinates the movement of the X, Y, and Z axes with precision. Its built-in fan cooling method ensures stable performance during extended cutting cycles. The module's overcurrent, overvoltage, overheating, and short circuit protections safeguard both the amplifier and the connected equipment, reducing downtime and maintenance costs.
Installation & Setup Guidance
When installing the A06B-6096-H301, ensure the ambient temperature stays within the 0 to 40 degrees Celsius range. Mount the module in a clean, dry location with adequate airflow for the built-in fan. Verify that the input voltage source matches the 283-325V requirement. Connect each axis output (L, M, N) to the corresponding servo motor, respecting the 3 Amp current limit per axis. Always follow the manufacturer's wiring diagrams and safety guidelines.
Maintenance & Reliability
Regularly inspect the built-in fan for dust accumulation and ensure it operates freely. Check all electrical connections for tightness and signs of wear. The module's comprehensive protection features—overcurrent, overvoltage, overheating, and short circuit—help prevent failures. Operate the unit within its specified altitude limit of 1000 meters to maintain performance. Periodic testing of the protection circuits is recommended to confirm they function correctly.
Selection Guide & Purchasing Advice
Before purchasing the A06B-6096-H301, verify that your CNC system requires a three-axis servo amplifier with a 1.85 kW power rating and 283-325V input. Confirm the physical dimensions and weight (22.00 lbs) fit your cabinet space. SpareTechPLC offers this module with detailed support to ensure compatibility with your existing FANUC setup. Contact our team for current availability and lifecycle status.
Frequently Asked Questions
Q1: How many axes does the A06B-6096-H301 support?
A: This module supports up to three axes (L, M, N), each with a 3 Amp output current.
Q2: What is the input voltage range for this servo amplifier?
A: The input voltage range is 283-325V.
Q3: Does the module include protection features?
A: Yes, it includes overcurrent, overvoltage, overheating, and short circuit protection.
Q4: What is the operating temperature range?
A: The operating temperature range is 0 to 40 degrees Celsius.
Q5: What cooling method does the A06B-6096-H301 use?
A: It uses a built-in fan for cooling.
