Product Overview
The GE Fanuc IC693CBL319 I/O Interface Cable is a critical link for Series 90-30 Axis Positioning Modules. This wye-type cable connects modules like the IC693APU301 and IC693APU302 to compatible drives and controllers. Each axis module requires two such cables to interface with its two male 24-pin connectors. Using the correct cable avoids costly downtime from signal mismatches or connector damage.
Technical Specifications Breakdown
Key parameters for the IC693CBL319 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Brand | GE Fanuc |
| Series | Series 90-30 |
| Part Number | IC693CBL319 |
| Description | I/O Interface Cable |
| Cable Length | 3.0 Feet |
| Connector Type | 24-Pin Female Connector and a 25-Pin D-type Terminal Block |
| Cable Type | Wye Type Cable |
| Application | Axis Positioning Modules |
| Wire Shield | Yes |
| Average Weight | 2.0 Pounds |
| Cable Housing | Yes |
| Conducting Material | 28 AWG Size Wire |
Industry Applications
This cable is designed for motion control systems using GE Fanuc Series 90-30 Axis Positioning Modules. Typical applications include packaging lines, material handling, and CNC machinery where precise axis coordination is required. Using the correct 3-foot cable reduces installation costs by minimizing excess cable routing and potential signal degradation.
Installation & Setup Guidance
Connect the 24-pin female connector to the male 24-pin connector on the axis module. Attach the 25-pin D-type terminal block to the drive or controller. Ensure the cable is routed away from high-voltage power lines to maintain signal integrity. The 28 AWG conductors are suitable for low-power I/O signals; verify drive compatibility before connection.
Maintenance & Reliability
The shielded construction and robust cable housing protect against electrical noise and physical wear. Periodically inspect connectors for bent pins or corrosion. Replace the cable if the shield continuity is compromised to avoid intermittent faults that can cause production stoppages.
Compatibility & Integration
The IC693CBL319 is compatible with GE Fanuc Series 90-30 Axis Positioning Modules, specifically the IC693APU301 and IC693APU302. For longer reach, consider the IC693CBL317 (3 meters) or IC693CBL320 (1 meter) which include an external drain shield wire for improved noise immunity in electrically harsh environments.
Selection Guide & Purchasing Advice
When selecting a replacement cable, verify the required length and connector type. The 3-foot length of this cable is ideal for compact cabinets where drives are mounted close to the controller. SpareTechPLC stocks this part for immediate shipment. Please verify current lifecycle status and availability with SpareTechPLC before ordering.
