Product Introduction
When your automation system requires reliable discrete input sensing, the GE IC200MDL640 Discrete Input Module delivers consistent performance. This Versamax series module from GE Fanuc provides 16 input points organized into 2 groups. It supports both positive and negative logic configurations, giving you flexibility in wiring field devices. The module operates on a nominal 24 Volts DC supply, with an input voltage range of 0 to 30 Volts DC. Its 10K Ohms input impedance ensures accurate signal detection.
Technical Specifications Breakdown
The IC200MDL640 offers several key specifications that define its capabilities. The module ID is FFFF8008, and it features 16 inputs divided into 2 groups. Input voltage ranges from 0 to 30 Volts DC, with a nominal value of 24 Volts DC. Input impedance is 10K Ohms. Group-to-group isolation is rated at 250 VAC continuous and 1500 VAC for 1 minute, while point-to-point isolation is none. LED indicators include one per point plus one "OK" LED. Backplane current consumption is 5 Volts at 25 milliamps. No external power supply is required.
Industry Applications
In manufacturing environments, the IC200MDL640 monitors limit switches and proximity sensors on assembly lines. Its 16 inputs in 2 groups allow you to connect multiple devices while maintaining electrical isolation between groups. The module's positive/negative logic capability suits both sourcing and sinking sensor types. For packaging machinery, this module reliably detects product presence and position, feeding data to the Versamax controller for precise timing.
Installation & Setup Guidance
Install the IC200MDL640 into any Versamax backplane slot. The backplane provides all necessary power, so no external supply is needed. During field wiring, use a shorting bar with the B terminal to arrange additional bussed terminals. The module supports hot insertion, but take care to avoid backplane disruptions during installation. Configure the input filter time via software: minimum 0 milliseconds, default 1.0 millisecond, maximum 7.0 milliseconds. The basic on/off response time per input is 0.5 milliseconds.
Maintenance & Reliability
Routine inspection of the IC200MDL640 involves checking LED indicators. Each point has its own LED, plus one "OK" LED for module status. No thermal derating is required. The module does not need an external power supply, reducing potential failure points. For reliable operation, ensure the backplane connection is secure and free from contamination. Periodically verify that input wiring is properly tightened and that the module's firmware is up to date.
Compatibility & Integration
The IC200MDL640 integrates seamlessly with GE Fanuc Versamax PLC systems. It communicates with a CPU or Network Interface Unit (NIU) that handles processing functions. The module is compatible with all Versamax backplanes that supply 5 Volts at 25 milliamps. No external power supply is needed, simplifying system design. For applications requiring isolation, the group-to-group isolation of 250 VAC continuous and 1500 VAC for 1 minute provides robust protection.
Selection Guide & Purchasing Advice
Before purchasing the IC200MDL640, verify that your system requires a 16-point discrete input module with 2 groups. Confirm that your backplane can supply 5 Volts at 25 milliamps. This module does not require an external power supply. For availability and current lifecycle status, contact SpareTechPLC. Our team can confirm stock levels and provide compatible accessories. Order the IC200MDL640 from SpareTechPLC for reliable Versamax expansion.
Frequently Asked Questions
Q: What is the input voltage range for the IC200MDL640?
A: The input voltage range is 0 to 30 Volts DC, with a nominal voltage of 24 Volts DC.
Q: How many input points does the IC200MDL640 have?
A: It has 16 input points divided into 2 groups.
Q: Does the IC200MDL640 require an external power supply?
A: No, the module draws power from the backplane at 5 Volts and 25 milliamps. No external supply is needed.
Q: What is the input impedance of the IC200MDL640?
A: The input impedance is 10K Ohms.
Q: Can the IC200MDL640 be used with both positive and negative logic sensors?
A: Yes, the module supports both positive and negative logic configurations.
