Lenze K-D M12A-3P-5m-PVC M12 Angled Connector Cable 5m

Technical Specifications Breakdown

Key parameters for the K-D M12A-3P-5m-PVC are listed below for quick reference:

Industry Applications

• Machine Building: Use this cable to connect proximity sensors, photoelectric sensors, and limit switches on automated assembly lines. The angled connector fits neatly into control cabinets and junction boxes, simplifying wiring and maintenance.
• Material Handling: Conveyor systems often require flexible cabling that can withstand continuous motion. The 5-meter length provides ample reach, while the PVC jacket protects against abrasion and impact.
• Packaging Equipment: In high-speed packaging machines, reliable signal transmission is critical. The K-D M12A-3P-5m-PVC ensures consistent performance even in environments with vibration and temperature fluctuations.

Installation and Setup Guidance

When installing the Lenze K-D M12A-3P-5m-PVC, follow these practical steps:

1. Verify voltage and current ratings: Ensure the connected device operates within the cable's rated limits (≤250 VAC/DC, ≤4 A per contact).
2. Route the cable properly: Avoid sharp bends and keep the bending radius at least 10 times the sheath diameter (per standard practice). For flexible wiring applications, ensure the cable is not subjected to tension or twisting.
3. Secure the connector: The M12 connector features a screw coupling. Tighten the coupling ring to the recommended torque of 0.6 Nm to ensure a watertight and vibration-resistant connection.
4. Check temperature range: For fixed installations, the cable can operate from -30°C to +70°C. For flexible wiring, the range is -5°C to +70°C. Do not exceed these limits.

Maintenance and Reliability

To maximize the service life of the K-D M12A-3P-5m-PVC, perform periodic inspections:

• Visual check: Look for cuts, abrasions, or discoloration on the PVC jacket.
• Connector integrity: Ensure the coupling ring is tight and free of corrosion.
• Cable strain relief: Verify that the cable is not pulled or stressed at the connector entry point.
• Environmental exposure: If the cable is exposed to chemicals or extreme temperatures, inspect more frequently.

Reliable M12 Connection Cable for Industrial Environments

Industrial automation systems depend on secure and durable connections between sensors, actuators, and controllers. The Lenze K-D M12A-3P-5m-PVC is a pre-assembled connection cable designed to deliver stable signal and power transmission in demanding factory floor conditions. This cable features an M12 angled socket, 3 pins, and a 5-meter PVC cable, making it a practical choice for space-constrained installations where a straight connector is not suitable.

Designed for Reliable Signal Transmission

The Lenze K-D M12A-3P-5m-PVC is engineered to maintain signal integrity in industrial settings. With a rated voltage of ≤250 VAC/DC and current capacity of ≤4 A per contact, it supports a wide range of sensors, actuators, and field devices. The PVC cable provides good resistance to oils, chemicals, and mechanical wear, making it suitable for machine tools, packaging lines, and material handling equipment.

The angled M12 connector reduces strain on the cable and allows installation in tight spaces where a straight plug would be impractical. This design minimizes the risk of accidental disconnection and cable damage, contributing to higher system uptime.

Compatibility and Integration

The Lenze K-D M12A-3P-5m-PVC is a standard M12 connector cable, compatible with a wide range of industrial devices that use M12 3-pin connections. It is commonly used with sensors, actuators, and I/O modules from various manufacturers. Always verify the pinout and wiring configuration to match your specific device.

Selection Guide and Purchasing Advice

When selecting a connection cable, consider the following factors:

• Cable length: The 5-meter length is suitable for most machine installations. For longer runs, consider a different length.
• If you need a straight connector, look for a different model.
• Cable material: PVC is cost-effective and offers good protection for most industrial environments. For higher flexibility or extreme temperatures, consider PUR or other materials.

At AutoDCSTech, we stock the Lenze K-D M12A-3P-5m-PVC and offer competitive pricing. Our team can assist you with technical questions and ensure you receive the right part for your application. Please verify current lifecycle status and availability with AutoDCSTech before ordering.

Troubleshooting and Common Issues

If you experience connectivity issues with the K-D M12A-3P-5m-PVC, consider these common causes:

• Loose connection: Ensure the M12 coupling is fully tightened to 0.6 Nm.
• Damaged cable: Inspect the entire length for cuts or kinks, especially at stress points.
• Incorrect wiring: Double-check the pinout against your device's wiring diagram.
• Overload: Verify that the connected load does not exceed 4 A per contact.
• Environmental stress: If the cable is exposed to temperatures outside the rated range, replace it with a suitable alternative.

For persistent issues, contact AutoDCSTech for technical support.
