Lenze K-D M8A-3P-2m-PVC M8 Cable with 3-Pin Connector

Technical Specifications Breakdown

Key parameters for the K-D M8A-3P-2m-PVC are listed below for quick reference:

Industry Applications and Operational Benefits

Compact Machine Design

Because the M8 connector is smaller than M12, the K-D M8A-3P-2m-PVC enables engineers to design more compact control cabinets and machine frames. This is especially valuable in robotic end-of-arm tooling and conveyor systems where space is at a premium. The 2-meter length provides enough reach for most sensor-to-controller distances without excessive cable slack.

Reliable Signal Integrity

With a current rating of ≤4A per contact and a voltage rating of ≤60VAC/DC, this cable handles typical sensor and actuator loads without derating. The PVC jacket offers good resistance to oils and chemicals commonly found in industrial environments, reducing the risk of cable degradation over time. This reliability translates into fewer false triggers and less unplanned maintenance.

Flexible Installation Options

The cable supports both fixed and flexible wiring, allowing it to be routed through cable carriers or moving machine parts. The -5°C to +70°C flexible range means it can be used in moderately cold environments without cracking, while the -30°C fixed range suits stationary installations in colder climates.

Installation and Setup Guidance

When installing the K-D M8A-3P-2m-PVC, follow these best practices:

• Torque: Tighten the M8 connector to the recommended torque of 0.6 Nm. Over-tightening can damage the threads, while under-tightening can cause intermittent contact.
• Bend Radius: Maintain a minimum bending radius of 10 times the sheath diameter. For a 4.9mm sheath, that means at least 49mm. Avoid sharp bends that could stress the conductors.
• Cable Routing: Use cable ties or clamps to secure the cable and prevent strain on the connector. Do not pull the cable by the connector body.
• Environmental Protection: The cable is designed for industrial use, but avoid direct exposure to extreme temperatures beyond the specified range. If used in wet areas, ensure the connector is properly sealed.

Maintenance and Reliability

Periodically inspect the cable for cuts, abrasions, or discoloration. Check the connector for signs of corrosion or loose fit. The self-locking screw fitting helps maintain a secure connection, but vibration can still loosen it over time. Re-torque to 0.6 Nm if necessary. Keep the cable away from sharp edges and hot surfaces to extend its service life.

The Lenze K-D M8A-3P-2m-PVC: A Reliable M8 Connection Cable for Industrial Sensors and Actuators

In automated production lines, a single failed connection can halt an entire process. The Lenze K-D M8A-3P-2m-PVC is a pre-assembled M8 connection cable designed to deliver stable signal and power transmission in tight spaces. With a 2-meter length and a 3-pin configuration, this cable suits proximity sensors, photoelectric sensors, and small actuators commonly found in packaging, material handling, and assembly machinery. Its robust construction helps minimize downtime caused by loose or damaged wiring.

Compatibility and Integration

The K-D M8A-3P-2m-PVC is a standard M8 3-pin cable, making it compatible with a wide range of M8 sensor and actuator ports from various manufacturers. It is not brand-specific, so it works with Lenze drives, as well as other industrial controls. Always verify the pinout and wiring diagram of your device before connecting.

Selection Guide and Purchasing Advice

When selecting a connection cable, consider the cable length, pin count, and environmental ratings. For longer runs or harsher conditions, consider a cable with a larger cross-section or a different jacket material. AutoDCSTech offers this cable for immediate purchase. Contact AutoDCSTech to confirm availability and lead times. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
