Lenze K-D M8W-4P-5m-PVC M8 Connection Cable – 5m PVC, 4-Pin

Technical Specifications Breakdown

Key parameters for the K-D M8W-4P-5m-PVC are listed below for quick reference:

Industry Applications

The 5m length offers flexibility in machine layouts, while the M8 connector ensures a compact, secure fit. With a rated current of ≤4A per contact and voltage up to ≤250VAC/DC, it suits both signal and low-power applications. The PVC jacket provides good resistance to oils and chemicals, making it suitable for machine tool environments.

Installation & Setup Guidance

When installing the K-D M8W-4P-5m-PVC, follow these best practices:

• Ensure the connector is fully seated and the screw fitting is tightened to the recommended torque of 0.6Nm (self-locking).
• For flexible wiring applications, respect the minimum bending radius of ≥10 × sheath diameter to prevent internal conductor damage.
• Avoid routing cables near sharp edges or high-temperature surfaces. Use protective conduit if necessary.
• Always disconnect power before connecting or disconnecting the cable.

Maintenance & Reliability

Periodically inspect the cable for cuts, abrasions, or signs of wear, especially in high-flex applications. Check that the connector remains tight and free of contamination. The operating temperature range of -30°C to +70°C (fixed) and -5°C to +70°C (flexible) should be respected to avoid insulation degradation. Replace any damaged cable immediately to prevent short circuits or signal loss.

Compatibility & Integration

The K-D M8W-4P-5m-PVC is designed for use with M8-compatible sensors and devices. It is a 4-pin, axial (A-type) connector with a 5-meter PVC cable. Ensure that your device's pinout matches the cable's wiring to avoid misconnection. For applications requiring higher pin counts or different cable materials, consider other Lenze K-D series options.

Selection Guide & Purchasing Advice

When selecting a connection cable, consider the environmental conditions, cable length, and connector type. The K-D M8W-4P-5m-PVC offers a balance of durability and flexibility for most industrial settings. At AutoDCSTech, we stock this cable and can advise on alternatives if your application demands special ratings. Contact our team for availability and lifecycle status before ordering.

Troubleshooting & Common Issues

If you experience intermittent signals or power loss, check the following:

• Verify that the connector is fully tightened and not loose.
• Inspect the cable for breaks or cuts, especially near the connector strain relief.
• Confirm that the operating temperature is within the specified range.
• Ensure that the cable is not subjected to excessive bending or pulling force.

By following these guidelines, you can maximize the reliability and lifespan of your M8 connection cable.
