Product Introduction
When high-power cabling demands reliability and clear organization, the Schneider Modicon Quantum 140XTS10215 system cable delivers. This 4.6-meter pigtail cable is engineered for demanding industrial environments where secure connections and easy identification are critical. Part of the trusted Modicon Quantum series, it integrates seamlessly into Schneider Electric's ecosystem.
Technical Specifications Breakdown
The 140XTS10215 is built around key parameters that ensure consistent performance. Its 4.6 m cable length provides flexibility for cabinet routing without excess slack. Designed as a pigtail cable, it includes 1 connector for Quantum I/O with 40 color-coded pigtail leads — each lead simplifies wiring identification and reduces installation errors. The cable is rated for high power applications, supporting robust current handling. Environmentally, it operates within an ambient temperature range of 0 to 40 degrees Celsius and tolerates 80% non-condensing humidity (both operating and storage). It also functions reliably at altitudes up to 1000 meters above sea level without derating. Weighing 4.50 lbs (2.04 kg), it balances durability with manageable weight.
Industry Applications
In large-scale manufacturing lines, the 140XTS10215 connects Quantum I/O modules to high-power actuators and motor starters, where the 40 color-coded leads speed up troubleshooting and reduce downtime. For process control systems in chemical plants, its temperature and humidity ratings ensure stable signal transmission even near heated vessels or in humid environments. The cable's altitude rating also makes it suitable for high-altitude installations such as mining operations or mountain-based facilities.
Installation & Setup Guidance
When installing the 140XTS10215, first verify that the ambient temperature stays within 0 to 40 degrees Celsius and humidity below 80% non-condensing. Secure the Quantum I/O connector firmly to the module, then route the 40 pigtail leads to their respective terminals. Use the color coding to match each lead to the correct I/O point — this reduces wiring errors and speeds commissioning. Avoid sharp bends or kinks in the 4.6 m cable to maintain signal integrity. Ensure the installation altitude does not exceed 1000 meters above sea level to guarantee full performance.
Maintenance & Reliability
Periodically inspect the 140XTS10215 cable for physical damage, especially near the connector and pigtail ends. Check that the ambient temperature stays within 0 to 40 degrees Celsius and that humidity remains below 80% non-condensing. Because this is a high-power cable, verify that all connections remain tight and free of corrosion. Regular inspection helps prevent unexpected failures and extends service life, maximizing return on investment by reducing unplanned downtime.
Compatibility & Integration
The 140XTS10215 is designed specifically for the Modicon Quantum series from Schneider Electric. It connects directly to Quantum I/O modules via its single connector, while the 40 pigtail leads interface with field devices. This cable is intended for high-power applications within the Quantum ecosystem. Always confirm that your Quantum I/O module supports high-power pigtail connections before ordering.
Selection Guide & Purchasing Advice
Before purchasing the 140XTS10215, verify your system's power requirements and confirm that a high-power pigtail cable is appropriate. Measure the distance between your Quantum I/O module and termination points to ensure 4.6 m is sufficient. For reliable sourcing, SpareTechPLC offers this genuine Schneider cable with full traceability. Contact our team to confirm current availability and lifecycle status before placing your order.
Frequently Asked Questions (FAQs)
Q1: What is the exact length of the 140XTS10215 cable?
A: The cable measures 4.6 meters from connector to pigtail ends.
Q2: How many pigtail leads does this cable have?
A: It includes 40 color-coded pigtail leads for easy identification.
Q3: What temperature range can the 140XTS10215 operate in?
A: It is rated for 0 to 40 degrees Celsius ambient temperature.
Q4: Is this cable suitable for high-humidity environments?
A: Yes, it can operate and be stored at up to 80% non-condensing humidity.
Q5: Can I use this cable at high altitudes?
A: Yes, it operates without derating up to 1000 meters above sea level.
