Product Overview
When industrial processes demand reliable switching of AC loads, the Schneider Electric TSXDSY16S5 discrete output module delivers consistent performance. Part of the TSX Micro PLCs series, this module provides 16 triac-protected outputs designed for robust operation in automation environments. It operates within a voltage range of 48 to 240 V AC, conforming to EN/IEC 61131-2 standards, making it suitable for a wide variety of control tasks.
Technical Specifications Breakdown
The TSXDSY16S5 offers key specifications that ensure reliable operation:
- Discrete Output Number: 16 outputs, each capable of handling up to 1 A of current, with a total module current of 12 A.
- Response Time: Both activation and deactivation occur in less than 10 ms, enabling fast switching for time-sensitive applications.
- Protection Features: Integrated fast-blow fuses provide short-circuit and output overload protection at 5 A. Output overvoltage protection uses a Ge-Mov element.
- Isolation: Isolation resistance exceeds 10 MOhm at 500 V, ensuring safe separation between circuits.
- Power Dissipation: Calculated as 0.85 W + 1 W per output multiplied by the current per module, allowing accurate thermal management.
Industry Applications
This module excels in applications requiring reliable AC output switching. Typical uses include:
- Motor Starters: Controlling contactors for small AC motors in conveyor systems or packaging machines.
- Lighting Control: Switching industrial lighting banks in warehouses or production areas.
- Valve Actuation: Operating solenoid valves in process control systems where triac outputs provide long life.
Installation & Setup Guidance
Mount the TSXDSY16S5 module onto a standard DIN rail within a TSX Micro PLC rack. Use the screw terminal block for secure electrical connections. Ensure the power supply provides 5 V DC with at least 220 mA for the module's current consumption. Verify that the AC load voltage stays within the 48 to 240 V AC range and that each channel does not exceed 1 A. The module has an IP20 protection rating, so install it inside a suitable enclosure to prevent dust ingress.
Maintenance & Reliability
To maintain reliable operation, periodically inspect the module for signs of overheating or loose connections. The integrated fuses protect against overloads, but if a fuse blows, replace it with the same 5 A fast-blow type. The module operates in ambient temperatures from 0 to 60 °C and can be stored from -25 to 70 °C. Keep the relative humidity below 95% without condensation to avoid damage.
Compatibility & Integration
The TSXDSY16S5 integrates seamlessly with Schneider Electric TSX Micro PLCs. It is also compatible with the Modicon Premium Automation platform. The module uses a screw terminal block for wiring, simplifying connection to field devices. It carries CE marking and complies with standards including IEC 61131-2, UL 508, and CSA C22.2 No 213, ensuring broad acceptance in global installations.
Selection Guide & Purchasing Advice
Before purchasing, verify that your PLC rack has an available slot and that your power supply can provide the required 220 mA at 5 V DC. Confirm that your loads are AC and within the 48-240 V range. The TSXDSY16S5 is available from SpareTechPLC, a trusted supplier of industrial automation parts. Contact us to check current availability and lifecycle status.
Frequently Asked Questions
Q: What is the maximum current per channel on the TSXDSY16S5?
A: Each channel can handle up to 1 A, with a total module current of 12 A.
Q: Does the module provide overvoltage protection?
A: Yes, it includes Ge-Mov output overvoltage protection.
Q: What type of output does this module have?
A: It has 16 triac-protected discrete outputs for AC loads.
Q: What is the response time of the outputs?
A: Both activation and deactivation occur in less than 10 ms.
Q: What certifications does the TSXDSY16S5 carry?
A: It carries CE marking and complies with IEC 61131-2, UL 508, and CSA C22.2 No 213, among others.
