Reliable Digital Input for Demanding Environments
When maintaining a distributed I/O system, engineers need components that offer both reliability and ease of service. The Schneider STBDDI3725KS basic digital input kit delivers exactly that, providing 16 discrete inputs at 24V DC within the Modicon STB platform. This kit simplifies installation and reduces downtime, making it a practical choice for modern industrial networks.
Technical Specifications and Performance
The STBDDI3725KS operates with a rated supply voltage of 24V DC and accepts input voltage limits from 11 to 30V at state 1, with a permissible voltage of 30V. Each discrete input draws 4.5 mA, ensuring consistent signal detection. The module features a response time of 2 ms for both off-to-on and on-to-off transitions, which supports fast and accurate monitoring in control applications.
Protection features include power protection via an integrated fuse on the PDM (time lag 5 A), input protection that is resistor-limited, and reverse polarity protection. Insulation between channels and the logic bus is rated at 1500 V for 1 minute, enhancing system safety. The module supports both cold swapping and hot swapping for basic NIMs, allowing for maintenance without system shutdown.
Application Scenarios in Manufacturing
In a typical packaging line, the STBDDI3725KS can monitor sensor inputs for product presence, position, and count. Its 16 discrete inputs handle multiple signals simultaneously, while the 2 ms response time ensures accurate timing for high-speed operations. The IP20 degree of protection makes it suitable for control cabinets in dry indoor environments.
Another common use is in material handling systems, where the module reads limit switches and proximity sensors. The wide operating temperature range of -25 to 70 °C (without derating) allows deployment in unconditioned factory floors. The module's compact dimensions (125 mm width, 18.4 mm height, 65.1 mm depth) save space in crowded panels.
Compatibility and Integration
The STBDDI3725KS is part of the Modicon STB distributed I/O solution and is designed for use with the I/O base STBXBA3000. It also works with power distribution modules STBPDT3100/3105. The kit includes the STBXTS1180 18-terminal screw type connector, the STBDDI3725 module, and the STBXBA3000 base, simplifying procurement and installation.
Frequently Asked Questions About the STBDDI3725KS
What is the input voltage range for the STBDDI3725KS?
The discrete input voltage is 24V DC, with input voltage limits of 11 to 30 V at state 1 and -3 to 5 V at state 0. The permissible voltage is 30 V.
Can the STBDDI3725KS be replaced without powering down the system?
Yes, the module supports hot swapping for basic NIMs, allowing replacement while the system remains operational. It also supports cold swapping.
What certifications does the STBDDI3725KS hold?
The product carries CE marking, UL certification, FM Class 1 Division 2, and CSA certification. It also complies with EN/IEC 61131-2 type 3 standards.
Why Choose AutoDCSTech for Your Automation Needs
AutoDCSTech specializes in industrial automation spare parts, offering genuine Schneider components like the STBDDI3725KS. Our team understands the importance of reliable supply chains and provides fast shipping to minimize downtime. Contact us for availability and lifecycle status before ordering.
