IC695CPE310 Buyer's Guide: Key Specs and Applications

Evaluating the IC695CPE310 for Your Automation Needs

When selecting a mid-range controller for industrial automation, engineers need a balance of processing power, communication flexibility, and memory capacity. The GE IC695CPE310, part of the PACSystems RX3i series, offers a 1.1 GHz microprocessor and 10 MB of user memory. This buyer's guide helps you assess whether this CPU module fits your application requirements.

Core Specifications and Performance

The IC695CPE310 delivers a Boolean execution speed of 0.72 ms/k, enabling fast logic processing for complex control tasks. It supports 32 K discrete I/O and 32 K analog I/O memory, providing ample capacity for medium-scale systems. The module uses SRAM and Flash memory, with battery-backed SRAM for data retention during power loss.

Power requirements are 1 Amp at +5 and +3.3 Volts DC, plus 0.5 Amps at +24 Volts DC. This low power draw simplifies power supply design in control cabinets. The CPU supports up to eight local racks, allowing system expansion without additional controllers.

Communication and Integration Capabilities

The IC695CPE310 includes one Ethernet port operating at 10/100 Mbps, two serial ports (one RS232 and one RS485), and one USB master port. The serial ports support SNP, Serial I/O, Modbus Slave, and Modbus Master protocols. This versatility enables connection to legacy devices and modern networks alike.

For fieldbus integration, the controller works with PROFINET, EGD, Modbus TCP Server and Client, Genius, Profibus DP, and Ethernet. This broad protocol support makes the IC695CPE310 suitable for diverse industrial environments, from discrete manufacturing to process control.

Application Scenarios

In automotive assembly lines, the IC695CPE310 manages sequential logic and safety interlocks with its fast Boolean execution speed. Its 32 K discrete I/O capacity handles numerous sensors and actuators, while the Ethernet port enables real-time data exchange with higher-level systems.

For chemical processing applications, the analog I/O memory of 32 K words supports precise monitoring of temperature, pressure, and flow. The Modbus RTU Slave and Master protocols allow integration with existing field devices, reducing retrofit complexity.

Real-World Application Example

Consider a packaging line where the IC695CPE310 coordinates multiple conveyor zones and labeling stations. The CPU's 1.1 GHz processor ensures rapid scan cycles, while the USB master port simplifies program updates via a thumb drive. This setup reduces downtime during changeovers and improves overall equipment effectiveness.

Compatibility and Upgrade Considerations

The IC695CPE310 uses a universal backplane and is compatible with Proficy Machine Edition Logic Developer 7.0 SIM 3 or later. Users can swap between CPU310 and CPE310 devices without upgrading legacy PME software. The module is compliant with EC RoHS DIRECTIVE 2002/95/EC, meeting environmental standards.

Please verify current lifecycle status and availability with AutoDCSTech before ordering, as product lifecycle information is not provided in the data.

Frequently Asked Questions

What is the user memory size of the IC695CPE310?

The IC695CPE310 has 10 MB of user memory, stored in SRAM and Flash memory. This provides ample space for medium to large control programs.

Which communication protocols does the IC695CPE310 support?

The serial ports support SNP, Serial I/O, Modbus Slave, and Modbus Master protocols. The Ethernet port supports SRTP at 10/100 Mbps. Additional fieldbus options include PROFINET, EGD, Modbus TCP, Genius, Profibus DP, and Ethernet.

How many local racks can the IC695CPE310 support?

The IC695CPE310 supports up to eight local racks, allowing system expansion without additional controllers. This scalability is ideal for growing automation systems.
