Lenze K-D M12A-3P-2m-PVC Connection Cable | 3-Pin M12, 2m PVC

Product Overview

The K-D M12A-3P-2m-PVC is a factory-assembled connection cable from Lenze. It features a 3-pin M12 connector on one end. The cable length is 2 meters, making it suitable for short-distance connections. The cable jacket is made of PVC, offering good flexibility and resistance to industrial oils and chemicals. This cable is designed for use in control cabinets, sensors, actuators, and other automation components. Its robust construction ensures reliable signal transmission in demanding environments.

Technical Specifications Breakdown

Key parameters for the K-D M12A-3P-2m-PVC are listed below for quick reference:

These specifications ensure compatibility with standard M12 ports. The 250VAC/DC rating covers most low-voltage control circuits. The 4A per contact capacity supports typical sensor and actuator loads. Always verify your system voltage and current requirements before installation.

Industry Applications

The K-D M12A-3P-2m-PVC is versatile. Use it in these scenarios:

• Sensor Connectivity: Connect proximity sensors, photoelectric sensors, and limit switches to PLC or I/O modules. The 3-pin configuration supports standard 3-wire sensors.
• Actuator Control: Interface solenoid valves, pneumatic actuators, or small motors. The 4A rating handles moderate inrush currents.
• Control Cabinet Wiring: Use it as a pre-made cable for internal panel wiring. The 2m length offers flexibility in layout.

This cable is an choice for new installations or as a replacement for worn-out cables. Its PVC jacket resists abrasion and many industrial fluids.

Installation & Setup Guidance

Proper installation ensures long service life. Follow these guidelines:

1. Check compatibility: Confirm the M12 connector matches your device port. Verify the pinout (3-pin) matches your signal requirements.
2. Route the cable: Avoid sharp bends and pinch points. Use cable ties or clamps to secure the cable along its path.
3. Tighten the connector: Hand-tighten the M12 nut, then use a wrench for a quarter turn. Do not overtighten.
4. Test continuity: After connection, use a multimeter to verify correct wiring. Check for shorts or open circuits.
5. Label the cable: Mark the cable for future identification, especially in complex panels.

Always disconnect power before connecting or disconnecting the cable.

Maintenance & Reliability

This cable is designed for long-term reliability. However, regular inspection is recommended:

• Visual check: Look for cuts, abrasions, or discoloration on the PVC jacket.
• Connector inspection: Ensure the locking nut is tight and the pins are clean and free of corrosion.
• Functional test: Periodically verify signal integrity through your control system.

If the cable shows signs of damage, replace it immediately to avoid intermittent faults.

The Evolution of Industrial Connectivity

Industrial automation has moved from hardwired relay panels to distributed I/O and smart sensors. This evolution demands reliable, standardized connection components. The Lenze K-D M12A-3P-2m-PVC connection cable represents that modern standard. It provides a secure, pre-wired link between field devices and control systems. This cable reduces installation time and minimizes wiring errors. For maintenance teams, it simplifies replacement and troubleshooting. The M12 connector has become the de facto interface in factories worldwide. This Lenze cable delivers the performance and durability that engineers expect.

Compatibility & Integration

The K-D M12A-3P-2m-PVC is a standard M12 cable. It works with any device that has an M12 3-pin female connector. This includes many Lenze drives and I/O modules, as well as third-party sensors and actuators. For longer distances, use extension cables or field-wireable connectors.

Selection Guide & Purchasing Advice

When selecting a connection cable, consider the pin count, length, and environmental rating. The K-D M12A-3P-2m-PVC meets most low-voltage industrial needs. For harsher environments, consider a PUR-jacketed cable. For higher pin counts, choose a 4-pin or 5-pin version.

We are a trusted supplier of industrial automation parts. Contact us to check availability and lead times. Our technical team can help you choose the right cable for your application.

Please verify current lifecycle status and availability with AutoDCSTech before ordering.
