Lenze K-D M12W-5P-10m-PVC M12 Connector Cable, 5-Pin, 10m

Technical Specifications Breakdown

Key parameters for the K-D M12W-5P-10m-PVC are listed below for quick reference:

Industry Applications

Its 5-pin design supports both signal and power transmission, reducing the need for multiple cables. The 10-meter length offers flexibility in machine layout, minimizing the need for extension connectors and reducing potential failure points. By using a pre-terminated cable, you save labor time and lower the risk of wiring errors, which translates to reduced downtime and lower total cost of ownership.

Installation & Setup Guidance

When installing the K-D M12W-5P-10m-PVC, ensure the connector is properly seated and the locking nut is tightened to the recommended torque of 0.6 Nm (self-locking). Avoid bending the cable below the minimum bending radius of ≥10 times the sheath diameter to prevent internal conductor damage. For fixed wiring, the cable can be used in temperatures from -30 °C to +70 °C; for flexible wiring applications, keep the temperature within -5 °C to +70 °C. Always route cables away from sharp edges and high-heat sources to extend service life.

Maintenance & Reliability

Regularly inspect the cable for signs of wear, especially at connection points and areas of flexing. The PVC jacket provides good resistance to oils and chemicals, but periodic checks are recommended in harsh environments. Ensure that the connector remains clean and free from moisture. Following these simple practices helps maintain signal integrity and prevents unexpected failures, ensuring long-term reliability and minimizing replacement costs.

Reliable M12 Connection Cable for Industrial Automation

In industrial automation, a dependable connection cable is the backbone of signal and power transmission. The Lenze K-D M12W-5P-10m-PVC is a pre-assembled M12 connector cable designed to deliver consistent performance in demanding environments. With a 5-pin configuration and a 10-meter PVC cable, this component simplifies installation and reduces wiring errors, making it a cost-effective choice for machine builders and maintenance teams.

Compatibility & Integration

The K-D M12W-5P-10m-PVC is a standard M12 5-pin cable, compatible with a wide range of industrial sensors and actuators that use M12 connectors. Its 10-meter length provides ample reach for distributed I/O setups. Always verify the pinout and voltage requirements of your device to ensure compatibility. This cable supports ≤125 VAC/DC and ≤4 A per contact, making it suitable for many low-power automation applications.

Selection Guide & Purchasing Advice

When selecting a connection cable, consider cable length, connector type, and environmental conditions. The Lenze K-D M12W-5P-10m-PVC offers a practical balance of length and durability. For pricing and availability, contact AutoDCSTech, your trusted supplier of industrial automation parts. Our team can help you confirm the correct part for your application and provide competitive quotes. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
