Schneider 170FNT11000 Modicon Momentum Fipio Communication Adapter

Product Overview

The Schneider Electric 170FNT11000 Fipio communication adapter is a critical component for the Modicon Momentum series, designed to enable reliable and high-speed data exchange in open industrial environments. This module addresses the need for robust connectivity in distributed control systems, supporting Fipio protocol at a data transmission rate of 1 Mbps. Its compact form factor and straightforward integration make it a practical choice for system integrators and plant engineers seeking to extend network reach without compromising performance.

Technical Specifications Breakdown

Key parameters for the 170FNT11000 are listed below for quick reference:

Industry Applications

This Fipio communication adapter is well-suited for manufacturing lines requiring long-distance device connectivity. With a maximum inter-device cable length of 5 km, it enables distributed I/O placement across large facilities, reducing wiring complexity. In process industries, the 1 Mbps data rate ensures timely data exchange for monitoring and control loops, while the open industrial structure allows integration with existing Fipio networks.

Installation & Setup Guidance

Mount the adapter on a Modicon Momentum I/O base, which supplies power. Use a Male Sub-D 9 connector for electrical connection. For fiber optic links, select either 62.5/125 or 50/125 multimode fiber. Ensure the ambient temperature remains between 0 and 60 °C. When planning the network, adhere to the maximum of 31 devices per segment without a repeater; use a repeater to extend to 61 devices if needed. Verify cable length does not exceed 5 km between devices.

Maintenance & Reliability

Periodically inspect the Sub-D 9 connector and fiber optic terminations for signs of wear or contamination. Keep the ambient temperature within the specified range to ensure reliable operation. The adapter's approvals (UL, CE, CSA) indicate compliance with international safety and performance standards, supporting long-term dependability in industrial settings.

Compatibility & Integration

The 170FNT11000 is part of the Modicon Momentum series and uses the Fipio protocol. The supply from the I/O base simplifies wiring, and the open industrial structure allows for flexible network topologies.

Selection Guide & Purchasing Advice

When selecting a Fipio communication adapter, verify network requirements such as device count and cable distance. The 170FNT11000 supports up to 61 devices with a repeater and 5 km cable runs, making it suitable for medium to large installations. AutoDCSTech offers this module with detailed specifications to assist in your decision. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
