Product Overview
In the fast-paced world of industrial automation, reliable data storage is critical for maintaining consistent operations. The Schneider Electric TSXMRPC007M flash memory module addresses this need by providing a compact and durable memory solution for TSX Micro PLCs. With a 512 KB capacity, this module ensures your programs and critical data remain intact even during power interruptions.
Technical Specifications Breakdown
The TSXMRPC007M delivers robust performance through carefully engineered specifications. Its flash memory type offers non-volatile storage, meaning data is retained for up to 10 years without power. The module withstands operating temperatures from 0°C to 60°C and storage conditions from -25°C to 70°C, making it suitable for demanding industrial environments. Humidity tolerance of 5% to 95% non-condensing ensures reliable operation in damp conditions. Shock resistance rated at 15 g for 11 ms and vibration resistance of 1.5 mm peak-to-peak from 3 Hz to 13 Hz protect against mechanical stress. Power consumption is a low 0.5 W, contributing to energy-efficient system design.
Industry Applications
Manufacturing facilities often face challenges with data loss during power fluctuations. The TSXMRPC007M prevents this by retaining critical program data for a decade. In packaging lines, where frequent recipe changes occur, the 100,000 write cycles allow repeated updates without wear concerns. For water treatment plants operating in humid environments, the module's 5% to 95% non-condensing humidity rating ensures consistent performance.
Installation & Setup Guidance
Mounting the TSXMRPC007M is straightforward using DIN rail mounting, a standard in control panel design. Ensure the module is securely clipped onto the rail before connecting to the TSX Micro PLC. Verify compatibility with your specific PLC model from the TSX Micro series before installation. Always power down the system before inserting or removing the memory module to prevent data corruption.
Maintenance & Reliability
Routine inspection of the module's connections and environmental conditions helps maximize its lifespan. The write endurance of 100,000 cycles supports frequent data updates in dynamic applications. Given the 10-year data retention, periodic verification of stored data integrity is recommended, especially in critical systems. The module's CE, UL, and CSA certifications confirm compliance with international safety and quality standards.
Compatibility & Integration
The TSXMRPC007M is specifically designed for Schneider Electric TSX Micro PLCs, ensuring seamless integration into existing automation architectures. It occupies slot 0 of the PLC rack and works with various processor models within the TSX Micro family. No additional software configuration is required for basic operation, making it a plug-and-play upgrade for expanding memory capacity.
Selection Guide & Purchasing Advice
Before purchasing, verify that your PLC model supports the TSXMRPC007M. This module is ideal for applications requiring reliable non-volatile storage with moderate capacity. For larger memory needs, consider alternative options in the TSX Micro lineup. SpareTechPLC stocks genuine Schneider Electric parts, ensuring authentic components for your automation systems. Contact our team for current availability and pricing.
Frequently Asked Questions
Q: What is the memory capacity of the TSXMRPC007M?
A: The module provides 512 KB of flash memory storage.
Q: How long does the TSXMRPC007M retain data without power?
A: Data retention is rated for up to 10 years under normal conditions.
Q: Can the TSXMRPC007M be used in high-vibration environments?
A: Yes, it withstands vibrations of 1.5 mm peak-to-peak from 3 Hz to 13 Hz.
Q: What certifications does the TSXMRPC007M hold?
A: It is certified CE, UL, and CSA.
Q: Is the TSXMRPC007M compatible with all TSX Micro PLCs?
A: It is compatible with Schneider Electric TSX Micro PLCs. Verify your specific model for support.
