Product Overview
When a production line suffers a controller failure, every minute of downtime costs money. The Schneider TSXP57104M provides a dependable solution for mid-range automation tasks. This compact controller module, part of the TSX Micro PLCs series, offers flexible memory options and robust processing capabilities to keep your operations running smoothly.
Technical Specifications Breakdown
The TSXP57104M delivers solid performance with an execution time of 0.19 µs for Boolean instructions without a PCMCIA card and 0.25 µs with the card installed. It handles up to 3.71 Kinst/ms (65% Boolean + 35% fixed arithmetic) without the PCMCIA card. Internal RAM provides 96 KB of data storage, expandable to 224 KB for programs when using a PCMCIA card. The module also supports a 256 KB additional data storage PCMCIA card.
For I/O handling, the controller supports up to 512 discrete I/O and 24 analogue I/O. It can manage 2 racks with 12 slots or 4 racks with 4, 6, or 8 slots. Communication is via a non-isolated serial link with 2 female mini DIN connectors at 19.2 kbit/s. The module draws 850 mA at 5 V DC.
Industry Applications
This controller excels in material handling systems where reliable discrete I/O control is critical. For example, in a conveyor sorting application, the TSXP57104M manages multiple sensors and actuators with its 512 discrete I/O capacity, ensuring accurate product routing. Its fast execution time minimizes delays in high-speed sorting operations.
In packaging machinery, the analogue I/O capability (24 channels) allows precise control of variable-speed drives and temperature sensors. The non-isolated serial link enables straightforward communication with operator interfaces or other controllers, simplifying integration.
Installation & Setup Guidance
Mount the TSXP57104M in a standard TSX Micro rack, ensuring proper alignment with the backplane connector. Secure the module using the provided screws. Connect the 5 V DC power supply to the backplane; the module draws 850 mA. For the serial link, use a compatible mini DIN cable (not included) and set the baud rate to 19.2 kbit/s in your Unity Pro software configuration. Verify that the green RUN LED illuminates after power-up.
Maintenance & Reliability
From a maintenance engineer's perspective, the TSXP57104M is designed for long-term reliability. The LEDs provide immediate status feedback: green for RUN, red for I/O faults, red for processor faults, and yellow for terminal port activity. Regularly inspect the module for dust accumulation and ensure ambient temperature stays within 32…140 °F (0…60 °C). The IP20 protection rating means it should be installed in a clean, dry enclosure. No internal adjustments are needed; simply replace the module if a fault occurs.
Compatibility & Integration
The TSXP57104M integrates seamlessly with the Modicon Premium automation platform and uses Unity Pro software for programming. It supports up to 2 communication modules, expanding connectivity options. The non-isolated serial link (RS485) at 19.2 kbit/s connects to HMIs, drives, or other serial devices. The controller is certified to UL 508, CSA C22.2 No 142, and IEC 61131-2 standards, ensuring broad compatibility in industrial environments.
Selection Guide & Purchasing Advice
Before purchasing the TSXP57104M, verify your required memory configuration: if you need more than 96 KB program memory, order a compatible PCMCIA card separately. Confirm your rack type and slot count (up to 32 slots total). For replacement, check that your existing power supply can provide 850 mA at 5 V DC. SpareTechPLC stocks this module and can advise on current availability and lifecycle status. Contact us to ensure the TSXP57104M meets your application needs.
Frequently Asked Questions
Q: What is the maximum program memory without a PCMCIA card?
A: Without a PCMCIA card, the TSXP57104M provides 96 KB of program and data memory.
Q: Can I use this controller with Unity Pro software?
A: Yes, the TSXP57104M is designed for Unity Pro programming software.
Q: What is the communication speed of the serial link?
A: The non-isolated serial link operates at 19.2 kbit/s.
Q: How many discrete I/O points can this controller handle?
A: It supports up to 512 discrete I/O points.
Q: What does the yellow LED indicate?
A: The yellow LED indicates activity on the terminal port (TER).
